UBIQUITI UNIFI UMR-ULTRA 2X10/100 FE LAN 1XNANOSIM IOT 4G/LTE CAT4 BELTÉRI VEZETÉK NÉLKÜLI IPARI ROUTER

• Mechanical

• Dimensions
• Without antennas: 84 x 82 x 26 mm (3.3 x 3.2 x 1")
• With antennas: 193.5 x 82 x 26 mm (7.6 x 3.2 x 1")
• Weight
• Device: 200 g (7.1 oz)
• DIN rail/wall mounts: 20 g (0.7 oz)
• Enclosure material
• Polycarbonate, aluminum alloy
• Mount material
• Polycarbonate

• Hardware

• Management interface
• Ethernet
• WiFi
• Networking interface
• (2) FE RJ45 ports
• LTE Category 4 radio
• WiFi 4
• Power supply
• USB Type-C (5V DC/2A)
• 4-pin* ATX DC power socket (9-30V DC)
• *Please refer to the Installation Guide for detailed power socket pinout.
• Max. power consumption
• 5.7W
• SIM
• nano SIM
• LTE bands
• B1, B2, B3, B4, B5, B7, B8, B12, B13, B18, B19, B20, B25, B26, B28, B66, B34, B38, B39, B40, B41
• 3G bands
• B1, B2, B4, B5, B6, B8, B19
• LTE throughput speed
• Download 150 Mbps / Upload 50 Mbps
• *Speed depends on network coverage and performance at the device location.
• WiFi standards
• WiFi 4, 2.4 GHz, 20/40 MHz
• Max. WiFi TX power
• 17 dBm
• Antenna SMA ports
• (1) Mobile 1: SMA female connector, supports 1Rx only
• (1) Mobile 2: SMA female connector, supports 1Tx and 1Rx
• (1) WiFi: RP-SMA female connector
• External antennas
• (2) Mobile/LTE antennas with SMA male connectors
• (1) WiFi antenna with RP-SMA male connector
• LED
• Status: blue/white
• Button
• Factory reset
• Mounting
• DIN rail/wall mount (Included)
• Ambient operating temperature
• -30 to 70° C (-22 to 158° F)
• Ambient operating humidity
• 10 to 90% noncondensing
• Certifications
• CE
• NDAA Compliant
• Yes

• Supported WiFi Data Rates

• 802.11b
• 1, 2, 5.5, 11 Mbps
• 802.11g
• 6, 9, 12, 18, 24, 36, 48, 54 Mbps
• 802.11n (WiFi 4)
• 6.5 Mbps to 150 Mbps (MCS0 - MCS7, HT 20/40)

Garancia fogyasztók részére

• 2 év kötelező jótállás (gyártó által biztosított szervizgarancia)

Garancia nem fogyasztók részére

• 1 év gyártó által biztosított szervizgarancia
