TP-LINK TL-MR100-OUTDOOR 4G 300 MBPS WI-FI OUTDOOR ROUTER

• 4G

• Network Type
• 4G
  FDD-LTE: B1/B3/B5/B7/B8/B20/B28 (2100/1800/850/2600/900/800/700 MHz)
  TDD-LTE: B38/B40/B41 (2600/2300/2500 MHz)
  3G: DC-HSPA+/HSPA/UMTS:B1/B5/B8(2100/850/900 MHz)
• Speed
• Download Speed 150 Mbps
  Upload Speed 50 Mbps
• SIM Type
• 1×Nano SIM Card

• HARDWARE

• Interface
• 1× 100 Mbps WAN/LAN Port (PoE In)
  1× Nano SIM Card Slot
  1 × DC Port
• Buttons
• 1× Reset Button
• Power
• 12V/1A DC
  48V/0.375A Passive PoE
  44-57V/0.35A 802.3af
• Dimensions (W x D x H)
• 8.9 x 3.9 x 2.2 in (226.6 x 100x 54.7mm)
• Antennas
• 2 × Detachable LTE Antennas

• WIRELESS FEATURES

• Wireless Standards
• IEEE 802.11b/g/n
• Frequency
• 2.4 GHz
• Signal Rate
• 300 Mbps
• Reception Sensitivity
• 11g 54M: -74 dBm
  11n HT20: -73 dBm
  11n HT40: -70 dBm
• Wireless Functions
• Enable/Disable Wireless Radio, Wireless Schedule, WMM, Wireless Statistics
• Wireless Security
• WPA/WPA2, WPA-PSK/WPA2-PSK encryptions

• SOFTWARE FEATURES

• Security
• DoS, IPv4 SPI Firewall, IP and MAC Address Binding
• Operating Modes
• 3G/4G Router, Wireless Router
• WAN Type
• Dynamic IP/Static IP/PPPoE/PPTP(Dual Access)/L2TP(Dual Access)
• Management Features
• Local Management, Remote Management
• DHCP
• Server, DHCP Client List, Address Reservation
• Port Forwarding
• ALG, Virtual Server, Port Triggering, UPnP, DMZ
• Dynamic DNS
• TP-Link, DynDns, NO-IP
• Protocols
• IPv4, IPv6
• Guest Network
• 2.4 GHz guest network
• Administration
• Upgrade Firmware, Factory Default, System Log, Diagnostic Tools

• OTHER

• Network Services Enabled by Default
• Web Server
  Manage and configure device through web (HTTP/HTTPS)
  Port: 80/443 Protocol: TCP
  DHCP Server
  IP address assignment (DHCP)
  Port: 67 Protocol: UDP
  DNS
  Port: 53 Protocol: TCP
  App management
  Manage and configure device through app
  Port: 22 Protocol: TCP
  Port: 20002 Protocol: TCP
  CWMP
  CPE WAN Management Protocol
  Port: 7547 Protocol: TCP

• OTHERS

• Package Content
• 1× TL-MR100-Outdoor Unit
  1× 10-meter RJ45 Ethernet Cable
  1× PoE Adapter
  1× AC Power Cord
  1× Quick Installation Guide
  Window/Pole/Wall Mounting Kits
• Requirements
• Edge, Firefox, Chrome, Safari, or other JavaScript-enabled browser
  *You are recommended to use the latest version
• Certifications
• CE, RoHS
• Environment
• Operating Temperature: -30°C~60°C (-22°F~140°F)
  Storage Temperature: -40°C~70°C (-40 °F~158 °F)
  Operating Humidity: 10%~90% RH
  Storage Humidity: 5%~90% RH
