TP-LINK SG5428X SWITCH 24X1000MBPS + 4X10GBPS SFP + 1XKONZOL PORT, MENEDZSELHETŐ

• HARDWARE FEATURES

• Interface
• 24× 10/100/1000 Mbps RJ45 Ports
• 4× 1/10 Gbps SFP+ Slots*
• 1× USB 2.0 Port
• 1× RJ45 Console Port
• 1× USB Type-C Console Port
• Fan Quantity
• Fanless
• Power Supply
• 100-240 V~50/60 Hz
• Dimensions ( W x D x H )
• 17.3 × 7.1 × 1.7 in (440 × 180 × 44 mm)
• Mounting
• Rackmountable
• Max. Power Consumption
• 19.6 W (220V/50Hz @ 25 °C)
• 19.9 W (110V/60Hz @ 25 °C)
• Max. Heat Dissipation
• 66.87 BTU/hr (220V/50Hz @ 25 °C)
• 67.86 BTU/hr (110V/60Hz @ 25 °C)

• PERFORMANCE

• Switching Capacity
• 128 Gbps per Unit
• Stacking
• Stacking Number: 4
• Stacking Port: 10G SFP+ Slot (all uplink ports can be used as stacking ports)
• Stacking Bandwidth: Up to 80 Gbps (4 stacking ports)
• Packet Forwarding Rate
• 95.23 Mpps
• MAC Address Table
• 16 K
• Packet Buffer Memory
• 12 Mbit
• Jumbo Frame
• 9 KB

• SOFTWARE FEATURES

• Quality of Service
• Class of Service
• 8 Queues of Priority
• Port Priority
• IEEE 802.1p Priority
• DSCP Priority
• Queue Min-Bandwidth
• Schedule Mode (SP, WRR, SP+WRR)
• Bandwidth Control
• Rate Limit
• Storm Control
• Voice VLAN
• User-Defined OUI
• Smoother Performance
• Action for Flows
• QoS remark (802.1P Remark, DSCP Remark)
• L3 Features
• IP Interfaces:
• IPv4: Max 128, IPv6: Max 128
• Static Routing
• IPv4 Max 512, IPv6: Max 128
• Host Route Table: Max 1,024 entries
• RIP: Version v1/v2, Max 1,796
• OSPF: Version v2/v3; v2: Max 1,796, v3: Max 450
• Static ARP: 512 static entries
• Dynamic ARP: 3,600 dynamic entries
• Proxy ARP
• DHCP Server:
• Max 64 IP Pools
• Max 1,000 Manual Binding Entries
• DHCP Relay:
• Relayed Interface
• Relayed VLAN
• L2 and L2+ Features
• Link Aggregation
• Spanning Tree Protocol
• Port-based and VLAN-based Loopback Detection
• 802.3x Flow Control
• ERPS
• Mirroring
• RSPAN
• MAC Address Table
• Multicast
• IGMP Snooping
• MLD Snooping
• L2 Multicast Table: Max 2,000
• Fast Leave
• Multicast VLAN Registration (MVR)
• Static Multicast Groups
• Multicast Filtering
• Advanced Features
• Automatic Device Discovery
• Batch Configuration
• Batch Firmware Upgrading
• Intelligent Network Monitoring
• Abnormal Event Warnings
• Unified Configuration
• Reboot Schedule
• ISP Features
• 802.3ah Ethernet Link OAM
• L2PT (Layer 2 Protocol Tunneling)
• Device Link Detect Protocol (DLDP)
• DDM
• sFlow
• VLAN
• Max 4K VLAN Group (802.1q VLAN)
• 802.1Q Tagged VLAN
• MAC VLAN Entries: 60
• Multicast VLAN
• Management VLAN
• VLAN VPN (QinQ): Max 256 entries
• GVRP
• Protocol VLAN: Protocol Template 16, Protocol VLAN 12 entries
• Voice VLAN
• Private VLAN
• Security
• Port Isolation
• CPU-Defend
• ARP Inspection (Dynamic ARP Inspection)
• DoS Defend
• IP-MAC-Port Binding
• 1,024 Entries
• DHCP Snooping
• ARP Inspection
• IPv4 Source Guard
• IPv6-MAC
• Port Binding
• 1,024 Entries
• DHCPv6 Snooping
• ND Detection
• ND Snooping
• IPv6 Source Guard
• DHCP Filter
• Static/Dynamic Port Security
• Up to 64 MAC addresses per port
• Broadcast/Multicast/Unknown-unicast Storm Control
• kbps/ratio control mode
• 802.1X
• Port base authentication
• Mac base authentication
• VLAN Assignment
• MAB
• Guest VLAN
• RADIUS authentication and accountability support
• AAA (including TACACS+)
• Secure web management through HTTPS with SSLv3/TLS 1.2
• Secure Command Line Interface (CLI) management with SSHv2
• IP/Port/MAC-based access control

• Management Features

• Omada App
• Yes. Requiring the use of the Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.
• Centralized Management
• Omada Cloud-Based Controller
• Omada Hardware Controller
• Omada Software Controller
• Cloud Access
• Yes. Requiring the use of the Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.
• Zero-Touch Provisioning
• Yes. Requiring the use of the Omada Cloud-Based Controller.
• Management Features
• Web-based GUI
• Command Line Interface (CLI) through console port, telnet
• SNMPv1/v2c/v3
• Trap/Inform
• RMON (1, 2, 3, 9 groups)
• SDM Template
• DHCP/BOOTP Client
• 802.1ab LLDP/LLDP-MED
• DHCP Auto Install
• Dual Image, Dual Configuration
• CPU Monitoring
• Cable Diagnostics
• Password Recovery
• SNTP
• System Log
• IEEE 802.3az Energy Efficient Ethernet (EEE)

• OTHERS

• Package Content
• SG5428X Switch
• Power Cord
• Console Cable
• Rackmount Kits
• Rubber Feet
• Quick Installation Guide
• System Requirements
• Microsoft© Windows© 98SE, NT, 2000, XP, Vista™ or Windows 7/8/10/11, MAC© OS, NetWare©, UNIX© or Linux.
• Environment
• Operating Temperature: -5 °C to 45 °C (23 °F to 113 °F)
• Storage Temperature: -40 °C to 70 ? (-40 ? to 158 ?)
• Operating Humidity: 10-90% RH non-condensing
• Storage Humidity: 5-90% RH non-condensing
