MERCUSYS MB235-4G 3G/4G MODEM + WIRELESS ROUTER AC1200 1XWAN/LAN(1000MBPS) +3XLAN(1000MPBS)

• Wireless

• Network Type
• EU:
• FDD-LTE: B1/B3/B5/B7/B8/B20/B28 (2100/1800/850/2600/900/800/700 MHz)
• TDD-LTE: B38/B40 (2600/2300 MHz)
• HSPA+/UMTS: B1/B5/B8 (2100/850/900 MHz)
• Wi-Fi Class
• AC1200
• Wi-Fi (2.4 GHz)
• 300 Mbps
• Wi-Fi (5 GHz)
• 867 Mbps
• Wireless Standards
• IEEE 802.11ac/a/b/g/n
• Frequency
• 5 GHz, 2.4 GHz
• Reception Sensitivity
• 11g 6Mbps: -95dBm
• 11g 54Mbps: -77dBm
• 11n HT20 MCS7: -74dBm
• 11n HT40 MCS7: -71dBm
• 11a 6Mbps: -92dBm
• 11a 54Mbps: -75dBm
• 11ac VHT20 MCS8: -70dBm
• 11ac VHT40 MCS9: -65dBm
• 11ac VHT80 MCS9: -61dBm
• Transmission Power
• 2.4 GHz < 20dBm (EIRP)
• 5 GHz < 23dBm (EIRP)
• Wireless Security
• WPA-PSK / WPA2-PSK / WPA3-SAE
• Wireless Functions
• smart connect
• WPS
• Wireless Schedule

• Software

• Operation Modes
• 3G/4G Router
• Wireless Router
• Cellular Mode
• 4G Mode
• 3G Mode
• Cellular APN
• Data Roaming
• Band Search
• Network Search
• Profile Create
• APN Settings
• ISP File Upgrade
• PIN Management
• WAN Mode
• Dynamic IP
• Static IP
• PPPoE
• PPTP
• L2TP
• DHCP
• Server
• DHCP Client List
• Address Reservation
• NAT Forwarding
• ALG
• Virtual Server
• Port Triggering
• UPnP
• DMZ
• Protocols
• IPv4, IPv6
• Data Settings
• Data Statistics
• Data Limit
• Guest Network
• 2.4 GHz Guest Network
• 5 GHz Guest Network
• Parental Controls
• Time Control
• Website Filtering
• DDNS
• MERCUSYS DDNS
• DynDns
• NO-IP
• SMS
• Inbox
• New Message
• Outbox
• Drafts
• QoS
• ?
• Security
• IPv4 SPI Firewall
• Access Control
• IP & MAC Binding
• IPv6 Firewall
• System Settings
• Time & Language
• LED Control
• Diagnostics
• Firmware Upgrade
• Backup&Restore
• Reboot
• Administration
• System Log
• CWMP Settings
• Device Management
• MERCUSYS APP
• Web GUI
• System Language
• English
• Deutsch
• Espanol
• Français
• Italiano
• Polski
• ???????
• TR-069
• Yes

• Hardware

• Dimensions
• 209 × 171.9 × 41.7 mm
• (8.2 × 6.8 × 1.6 in)
• Antenna
• 2× External Detachable 4G LTE Antennas,
• 2× External Wi-Fi Antennas
• Interfaces
• 1× Gigabit LAN/WAN Port
• 3× Gigabit LAN Ports
• 1× Nano SIM Card Slot
• Button
• WPS, Reset Button
• External Power Supply
• 12V/1A
• LED
• 1× Power
• 1× Internet
• 1× LAN
• 3× Signal
• LTE Standard
• Cat 6
• 300/50Mbps DL/UL

• Others

• Environment
• Operating Temperature: 0°C~40°C (32°F~104°F)
• Storage Temperature: -40°C~60°C (-40°F~140°F)
• Operating Humidity: 10%~90% Non-Condensing
• Storage Humidity: 5%~90% Non-Condensing
• Package Contents
• 4G+ Cat6 AC1200 Wireless Dual Band Gigabit Router (MB235-4G)
• Power Adapter
• RJ45 Ethernet Cable
• Quick Installation Guide
