ZYXEL FWA-510-EU0102F 4G/5G LTE MODEM + WIRELESS ROUTER DUAL BAND AX3600 2X2.5G + 1XUSB + 1 ÉV NEBULA PRO LICENSE

• System specifications

• IP networking
• Supports IPv4/IPv6 dual stack (NDP IPv6)
• DHCP server
• Virtual Private Network (VPN) pass-through
• Supports NAT/NAPT
• Supports DMZ
• Multiple APNs
• Supports port forwarding
• Routing
• Supports bridge and router modes
• Supports remote management under bridge mode
• Static/dynamic routing settings for RIP v1/v2
• IP firewall
• DoS attack detection
• Supports SPI (Stateful Packet Inspection)
• Application-level firewall (LAN to WAN such as HTTP, Telnet, Ping)
• Filters LAN MAC address
• Filters LAN IP address
• Management
• Supports local/remote device management and firmware upgrade via Nebula Cloud and web GUI
• SMS management
• PIN/PUK manage ment
• APN management
• Operating frequency band selection
• Supports Zyxel Air app (iOS and Android) for easy installation and local management only
• WLAN feature
• Auto channel selection
• WiFi Protected Setup (WPS)
• WiFi Multimedia (WMM)
• WiFi-enabled devices: up to 64
• Security: none, WPA2-Personal, WPA+WPA2, WPA2+WPA3, WPA3
• MAC address filtering with 64 address supported
• Multiple SSIDs/hide SSIDs
• WLAN scheduling

• Hardware Specifications

• 5G NR interface
• 3GPP Release 15 standard-compliant
• Supports both NSA and SA modes
• Supports Sub-6 NR DL 2xCA (TDD/FDD)
• Supports frequencies:
• FDD: n1, n3, n5, n7, n8, n20, n28
• TDD: n38, n40, n41, n77, n78
• Supports DL 4×4 MIMO:
• FDD: n1, n3, n5, n7
• TDD: n38, n40, n41, n77, n78
• Data rates:
• 5G SA: DL 4.67 Gbps*; UL: 2.5 Gbps*
• 5G NSA: DL 3.74 Gbps*; UL: 1.46 Gbps*
• Output power:
• Class 2 (26 dBm) for 5G NR n41/n78
• Class 3 (23 dBm) for all 5G NR bands
• 4G LTE interface
• 3GPP UE Category 19 standard-compliant
• Supports frequencies:
• LTE-FDD: B1/B3/B5/B7/B8/B20/B28/B32
• LTE-TDD: B38/B40/B41/B42
• Supports DL 4×4 MIMO:
• LTE-FDD: B1/B3/B7
• LTE-TDD: B38/B40/B41/B42
• Peak data rates:
• Max. DL 1.6 Gbps/UL 200 Mbps**
• Supports DL modulation QPSK, 16-QAM, 64-QAM and 256-QAM
• Supports UL modulation QPSK, 16-QAM, 64-QAM and 256-QAM
• Output power:
• Class 2 (26 dBm) for LTE B41
• Class 3 (23 dBm) for FDD/TDD LTE bands
• WiFi air interface
• Wireless standard:
• IEEE 802.11 b/g/n/a/ac/ax
• Wireless speeds:
• Link rates up to 1.2 Gbps** for 2.4 GHz
• Link rates up to 2.4 Gbps** for 5 GHz
• WiFi antenna gain:
• ~3 dBi for 2.4 GHz
• ~5 dBi for 5 GHz
• 5G NR/4G LTE antennas
• Four TS9 connectors for external antennas***
• Four embedded omni-directional antennas
• Ultra-high band:
• Up to 5 dBi peak gain
• High band and middle band:
• Up to 5 dBi peak gain
• Low band:
• Up to 4 dBi peak gain
• Hardware interface
• Two 100/1000/2500 Mbps Ethernet RJ-45 LAN ports, LAN2 can be configured for Ethernet WAN port
• LED indicators:
• Power indication
• SMS status
• Signal strength
• Internet connection status
• Radio access technology status
• WiFi AP status
• WPS status
• Four external antenna connectors (TS9 type)***
• One 3FF/Micro SIM card slot
• One power on/off button
• One WPS/WiFi on/off button
• One reset button
• One Int/Ext antenna switch
• One USB 3.0 host port for file sharing

• Power consumption

• 48 W (peak)

• Physical Specifications

• Item
• dimensions (WxDxH):
• 132.5 x 134 x 230 mm (5.22" x 5.28" x 9.06")
• weight:
• 1,006 g (2.22 lb.)
• Packing
• dimensions (WxDxH):
• 250 x 200 x 140 mm (9.84" x 7.87" x 5.51")
• weight:
• 1,504 g (3.32 lb.)

• Environmental Specifications

• Operating Environment
• Temperature:
• 0°C to 40°C (32°F to 104°F)
• Humidity:
• 10% to 90% (non-condensing) Storage Environment
• Storage Environment
• Temperature:
• -30°C to 70°C (-22°F to 158°F)
• Humidity:
• 5% to 95% (non-condensing)

• Package Contents

• EU/UK power adaptor
• Ethernet cable 1.8 m 8P8C
• Quick start guide
• Warranty card
• DoC
• Safety warranty
