TP-LINK ER7406 VEZETÉKES VPN ROUTER 1XWAN(1000MBPS)+ 4XWAN/LAN(1000MBPS) + 1XSFP + 1XUSB

• SECURITY

• Access Control
• Source/Destination IP Based Access Control
• Filtering
• . WEB Group Filtering
• . URL Filtering
• . Web Security
• ARP Inspection
• . Sending GARP Packets
• . ARP Scanning
• . IP-MAC Binding
• Attack Defense
• . TCP/UDP/ICMP Flood Defense
• . Block TCP Scan (Stealth FIN/Xmas/Null)
• . Block Ping from WAN

• HARDWARE FEATURES

• Standards and Protocols
• . IEEE 802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE 802.3x, IEEE 802.1q
• . TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP, L2TP, OpenVPN, WireGuard VPN, GRE VPN, SNMP
• Interface
• . 1 Gigabit SFP WAN/LAN Port
• . 1 Gigabit WAN Port
• . 4 Gigabit LAN/WAN Ports
• . 1 USB 3.0 Port (supports USB LTE dongle and USB storage)
• Network Media
• . 10BASE-T: UTP category 3, 4, 5 cable (Max 100 m) EIA/TIA-568 100? STP (Max 100 m)
• . 100BASE-TX: UTP category 5, 5e cable (Max 100 m) EIA/TIA-568 100? STP (Max 100 m)
• . 1000BASE-T: UTP category 5, 5e, 6 cable (Max 100 m)
• Fan Quantity
• Fanless
• Button
• Reset Button
• Power Supply
• 100-240VAC, 50/60Hz
• Flash
• 128 MB NAND
• DRAM
• 512 MB DDR4
• LED
• PWR, SYS, SFP, USB, WAN(1000M Link/Act, 100/10M Link/Act), WAN/LAN (1000M Link/Act, 100/10M Link/Act)
• Dimensions ( W x D x H )
• 11.6 × 5.5 × 1.7 in (294 × 140 × 44 mm)
• Protection
• 4 kV surge protection
• Enclosure
• Steel
• Mounting
• . Desktop
• . Rackmountable
• Max Power Consumption
• . 7.5 W (with USB 3.0 connected)
• . 4.5 W (without USB 3.0 connected)

• PERFORMANCE

• IPS Throughput
• TCP: 229 Mbps;
• UDP: 188 Mbps
• DPI Throughput
• TCP: 933 Mbps;
• UDP: 927 Mbps
• GRE
• . Unencrypted: 611.9 Mbps
• . Encrypted: 325.0 Mbps
• WireGuard VPN
• 341.3 Mbps
• Concurrent Session
• 150,000
• New Sessions /Second
• 5,300
• NAT (Static IP)
• 945.3 Mbps / 940.5 Mbps
• NAT(DHCP)
• 939.6 Mbps / 940.9 Mbps
• NAT(PPPoE)
• 943.6 Mbps / 940.9 Mbps
• NAT (L2TP)
• 880.1 Mbps / 859.0 Mbps
• NAT (PPTP)
• 855.0 Mbps / 907.2 Mbps
• IPsec VPN Throughput
• . ESP-SHA1-AES256: 617.1 Mbps
• . ESP-SHA256-AES256: 592.8 Mbps
• . ESP-SHA384-AES256: 592.4 Mbps
• . ESP-SHA512-AES256: 604.5 Mbps
• OpenVPN
• 139.1 Mbps
• L2TP VPN Throughput
• . Unencrypted: 977.4 Mbps
• . Encrypted: 334.6 Mbps
• PPTP VPN Throughput
• . Unencrypted: 1064.1 Mbps
• . Encrypted: 206.8 Mbps
• SSL VPN Throughput
• 131.6 Mbps
• 66 Byte Packet forwarding rate
• 1,453,489 pps / 1,453,488 pps
• 1,518 Byte Packet forwarding rate
• 81,279 pps / 81,275 pps

• BASIC FUNCTIONS

• WAN Connection Type
• . Static IP
• . Dynamic IP
• . PPPoE(supports MRU Configuration)
• . PPTP
• . L2TP
• MAC Clone
• Modify WAN/LAN MAC Address (LAN MAC Address can be modified only in Standalone Mode)
• DHCP
• . DHCP Server
• . DHCPv6 PD Server (only in Standalone Mode)
• . DHCP Options Customization
• . DHCP Address Reservation
• . Multi-IP Interfaces
• . Multi-Net DHCP
• IPv6
• StaticIP/SLAAC/DHCPv6/PPPoE/6to4Tunnel/PassThrough/Non-Address mode
• VLAN
• 802.1Q VLAN
• IPTV
• IGMP v2/v3 Proxy, Custom Mode, Bridge Mode

• ADVANCED FUNCTIONS

• Advanced Routing
• . Static Routing
• . Policy Routing
• . RIP (available in Standalone Mode)
• . OSPF (available in Standalone Mode)
• Bandwidth Control
• IP-based Bandwidth Control
• Load Balance
• . Intelligent Load Balance
• . Application Optimized Routing
• . Link Backup (Timing, Failover)
• . Online Detection
• NAT
• . One-to-One NAT
• . Multi-Net NAT
• . Port Forwarding
• . Port Triggering§
• . NAT-DMZ
• . FTP/H.323/SIP/IPSec/PPTP ALG
• . UPnP
• Session Limit
• IP-based Session Limit

• VPN

• GRE
• (Only in Standalone Mode)
• SSL VPN
• 50 Tunnels
• IPsec VPN
• . 100 IPSec VPN Tunnels
• . LAN-to-LAN, Client-to-LAN
• . Main, Aggressive Negotiation Mode
• . DES, 3DES, AES128, AES192, AES256 Encryption Algorithm
• . IPsec Failover
• . IKE v1/v2
• . MD5, SHA1, SHA2-384 and SHA2-512 Authentication Algorithm
• . NAT Traversal (NAT-T)
• . Dead Peer Detection (DPD)
• . Perfect Forward Secrecy (PFS)
• PPTP VPN
• . PPTP VPN Server
• . PPTP VPN Client (10)**
• . 50 Tunnels
• . PPTP with MPPE Encryption
• L2TP VPN
• . L2TP VPN Server
• . L2TP VPN Client (10)**
• . 50 Tunnels
• . L2TP over IPSec
• OpenVPN
• . OpenVPN Server
• . OpenVPN Client (5)**
• . 55 OpenVPN Tunnels
• . "Certificate + Account" Mode
• . Full Mode

• AUTHENTICATION

• Web Authentication
• . No Authentication
• . Simple Password*
• . Hotspot (Local User /Voucher*/ SMS/Radius*)
• . External Radius Server
• . External Portal Sever<*
• . LDAP

• MANAGEMENT

• Omada App
• Yes. Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.
• Centralized Management
• . Omada Cloud-Based Controller
• . Omada Hardware Controller
• . Omada Software Controller
• Cloud Access
• Yes. Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.
• Service
• Dynamic DNS (Dyndns, No-IP, Peanuthull, Comexe, DDNS Customization)
• Maintenance
• . Web Management Interface
• . Remote Management
• . Export & Import Configuration
• . SNMP v1/v2c/v3
• . Diagnostics (Ping & Traceroute) (only in Standalone Mode)
• . NTP Synchronize (only in Standalone Mode)
• . Port Mirroring
• . CLI (only in Standalone Mode)
• . Syslog Support
• Zero-Touch Provisioning
• Yes. Requires the use of Omada Cloud-Based Controller.
• Management Features
• . Automatic Device Discovery*
• . Batch Configuration*
• . Batch Firmware Upgrading*
• . Intelligent Network Monitoring*
• . Abnormal Event Warnings*
• . Unified Configuration*
• . Reboot Schedule*

• OTHERS

• Certification
• CE, FCC, RoHS
• Package Contents
• . ER7406
• . Power Cord
• . Quick Installation Guide
• . Rackmount Kit
• System Requirements
• . Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7/8/8.1/10
• . MAC OS, NetWare, UNIX or Linux
• Environment
• . Operating Temperature: 0 °C to 50 °C (32 °F to 122°F)
• . Storage Temperature: -40 °C to 70 °C (-40 °F to 158 °F)
• . Operating Humidity: 10% to 90% non-condensing
• . Storage Humidity: 5% to 90% non-condensing
