TP-LINK ER605W VEZETÉKES VPN ROUTER 1XWAN(1000MBPS) + 2XWAN/LAN(1000MBPS) + 2XLAN(1000MBPS)

• SECURITY

• Access Control
• Source/Destination IP Based Access Control
• DNS Proxy
• DNSSEC, DoH, and DoT
• Filtering
• Web Group Filtering
• URL Filtering
• Web Security
• ARP Inspection
• Sending GARP Packets
• ARP Scanning
• IP-MAC Binding
• Attack Defense
• TCP/UDP/ICMP Flood Defense
• Block TCP Scan (Stealth FIN/Xmas/Null)
• Block Ping from WAN

• HARDWARE FEATURES

• Interface
• 1× Gigabit WAN Port
• 2× Gigabit WAN/LAN Ports
• 2× Gigabit LAN Ports
• Button
• Reset Button
• Power Supply
• 12V DC / 1A Power Adapter
• Wi-Fi Frequency & Signal Rate
• 2.4 GHz: 300 Mbps
• 5 GHz: 867 Mbps
• Flash
• 128 MB NAND
• DRAM
• 256 MB DDR3
• LED
• Power, SYS, 2.4G, 5G
• WAN (1000/100/10M Link/Act),
• WAN/LAN (1000/100/10M Link/Act)
• LAN (1000/100/10M Link/Act)
• Dimensions ( W x D x H )
• 8.5 × 4.6 × 1.2 in (215 × 117 × 31 mm)
• Antenna
• 2.4 GHz: 2× 5 dBi non-detachable antennas
• 5 GHz: 2× 5 dBi non-detachable antennas
• Mounting
• Desktop/Wall-mounting
• Max. Power Consumption
• EU: 9W

• PERFORMANCE

• GRE
• Unencrypted: 180.1 Mbps
• Encrypted: 56.9 Mbps
• WireGuard VPN
• 71.2 Mbps
• Concurrent Session
• 50,000
• New Sessions /Second
• 2,028
• NAT (Static IP)
• 909.3Mbps/937.5 Mbps
• NAT(DHCP)
• 938.3 Mbps /888.2 Mbps
• NAT(PPPoE)
• 929.9 Mbps /929.2 Mbps
• NAT (L2TP)
• 346.9 Mbps /337.6 Mbps
• NAT (PPTP)
• 487.1 Mbps/454.3 Mbps
• IPsec VPN Throughput (AES256)
• ESP-SHA1-AES256: 175.5 Mbps
• ESP-SHA256-AES256: 185.9 Mbps
• ESP-SHA384-AES256: 30.9 Mbps
• ESP-SHA512-AES256: 30.7 Mbps
• OpenVPN
• 16.8 Mbps
• L2TP VPN Throughput
• Unencrypted: 400.3 Mbps
• Encrypted: 127.5 Mbps
• PPTP VPN Throughput
• Unencrypted: 523.6 Mbps
• Encrypted: 52.7 Mbps
• 66 Byte Packet Forwarding Rate
• 1,453,489 pps /1,453,489 pps
• 1,518 Byte Packet forwarding rate
• 81,275 pps / 81,275 pps

• WIRELESS FEATURES

• Advanced Features
• Multiple SSIDs: 16 in total (8 per radio)
• Enable/Disable Wireless Radio
• Enable/Disable SSID Broadcast
• Automatic Channel Selection Algorithm
• Transmit Power Control: Adjust transmit Power on dBm
• Rate Limit: Based on SSID/Client
• Load Balance
• Band Steering
• RADIUS Accounting
• MAC Authentication
• Wireless Schedule
• Wireless Encryption: WPA/WPA2 Personal, WPA/WPA2 Enterprise

• BASIC FUNCTIONS

• WAN Connection Type
• Static IP
• Dynamic IP
• PPPoE (supports MRU Configuration)
• PPTP
• L2TP
• MAC Clone
• Modify WAN Address
• DHCP
• DHCP Server
• DHCPv6 PD Server (only in Standalone Mode)
• DHCP Options Customization
• DHCP Address Reservation
• Multi-IP Interfaces
• Multi-Net DHCP
• Stateful ACL
• Yes
• Quality of Service
• Yes
• Bridge VLAN
• Yes
• mDNS Repeater
• Yes
• IPv6
• StaticIP / SLAAC / DHCPv6 / PPPoE / 6to4Tunnel / PassThrough / Non-Address mode
• VLAN
• 802.1Q VLAN
• IPTV
• IGMP v2/v3 Proxy, Custom Mode, Bridge Mode

• Advanced Features

• Advanced Routing
• Static Routing
• Policy Routing
• RIP
• OSPF
• Bandwidth Control
• IP-Based Bandwidth Control
• Load Balance
• Intelligent Load Balance
• Application Optimized Routing
• Link Backup(Timing, Failover)
• Online Detection
• NAT
• One-to-One NAT
• Multi-Net NAT
• Virtual Server
• Port Triggering?
• NAT-DMZ
• FTP/H.323/SIP/IPSec/PPTP ALG
• UPnP
• Session Limit
• IP-Based Session Limit

• VPN

• GRE
• Only in Standalone Mode
• IPsec VPN
• 6 IPSec VPN Tunnels
• LAN-to-LAN, Client-to-LAN
• Main, Aggressive Negotiation Mode
• DES, 3DES, AES128, AES192, AES256 Encryption Algorithm IPsec
• Failover
• IKE v1/v2
• MD5, SHA1, SHA-256, SHA2-384 and SHA2-512 Authentication
• Algorithm NAT Traversal (NAT-T)
• Dead Peer Detection (DPD)
• Perfect Forward Secrecy (PFS)
• PPTP VPN
• PPTP VPN Server
• PPTP VPN Client (6) 6 Tunnels
• PPTP with MPPE Encryption
• L2TP VPN
• L2TP VPN Server L2TP VPN Client (6) 6 Tunnels
• L2TP over IPSec
• OpenVPN
• OpenVPN Server OpenVPN Client (3)
• 18 OpenVPN Tunnels
• "Certificate + Account" Mode
• Full Mode
• WireGuard VPN
• Yes

• AUTHENTICATION

• Web Authentication
• No Authentication
• Simple Password§
• Hotspot (Local User / Voucher§ / SMS§ / Radius§)
• External Radius Sever
• External Portal Sever§
• LDAP

• Management Features

• Omada App
• Yes.
• Centralized Management
• Omada App
• Omada Hardware Controller
• Omada Software Controller
• Service
• Dynamic DNS (Dyndns, No-IP, Peanuthull, Comexe, DDNS Customization)
• Maintenance
• Web Management Interface
• Remote Management
• Export & Import Configuration
• Diagnostics (Ping & Traceroute)?
• NTP Synchronize
• Port Mirroring
• Syslog Support
• Management Features
• Automatic Device Discovery
• Intelligent Network Monitoring
• Abnormal Event Warnings
• Unified Configuration
• Reboot Schedule
• Captive Portal Configuration

• OTHER

• Network Services Enabled by Default
• Web Server
• Manage and configure device through web (HTTP/HTTPS)
• Port: 80/443 Protocol: TCP
• _____________________________________________________
• TDP Server
• Device discovery
• Port: 20003 Protocol: UDP
• _____________________________________________________
• DHCP Server
• Handle DHCP packets
• Port: 67 Protocol: UDP
• _____________________________________________________
• DNS
• Handle DNS packets
• Port: 53 Protocol: TCP/UDP

• OTHERS

• Certification
• CE, FCC, RoHS
• Package Content
• ER605W
• Power Adapter
• Ethernet Cable
• Quick Installation Guide
• System Requirements
• Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7/8/8.1/10/11
• MAC OS, NetWare, UNIX or Linux
• Environment
• Operating Temperature: 0 °C to 40 °C (32 °F to 104 °F)
• Storage Temperature: -40 °C to 70 °C (-40 °F to 158 °F)
• Operating Humidity: 10% to 90% non-condensing
• Storage Humidity: 5% to 90% non-condensing

Garancia fogyasztók részére

• 2 év kötelező jótállás + 3 év gyártó által biztosított szervizgarancia

Garancia nem fogyasztók részére

• 5 év gyártó által biztosított szervizgarancia
