ELO TOUCH ET1504LS-2UWA-1-GY-NS-G ÉRINTŐKÉPERNYŐS MONITOR (USB-C)

Kijelző

• Képátló: 15.6"
  Felbontás: 1920x1080
  Panel: TFT-LCD
  Képarány: 16:9

Csatlakozók

• • 0x VGA
  • 0x DVI
  • 0x DisplayPort
  • 0x HDMI
  • TV-tuner

• Characteristics

• case color
• Dark Gray Metallic
• Touch Technology & Performance
• PCAP (projected capacitive sensing) - 10-Touch
• screen diagonal
• 15.6 inch diagonal, active matrix TFT LCD (LED)
• aspect ratio
• 16:9
• Active area
• 13.55'' x 7.62'' / 344.16mm x 193.59mm
• resolution
• 1920 x 1080
• Other supported resolutions
• 640x480 60Hz
• 800x600 60Hz
• 1024x768 60Hz
• 1280x800
• 60Hz 1280x720 60Hz
• 1280x1024 60Hz
• 1366x768 60Hz, 60Hz RB
• 1440x900 60Hz, 60Hz RB
• 1680 x1050 60Hz, 60Hz RB
• 1920x1080 60Hz
• perspective
• Horizontal: ?85° or 170° total / Vertical: ?85° or 170° total
• Colors
• 16.2 million
• brightness (typical)
• LCD panel: 350 cd/m2
• PCAP: 315 cd/m2
• Total response time (typical)
• 20 ms
• contrast ratio
• 1000:1
• touch interfaces
• USB
• surface treatment
• glare protection
• On-Screen Display (OSD)
• Touchscreen Access: Press the Menu button to bring up the touchscreen OSD diagram.
• Controls: Menu, POWER
• Settings: Brightness, Contrast, Color Temperature, Blue Light Filter, Volume, Mute, Display Timeout, Display Language, Sharpness, Touch on Standby, POWER LED, Touch Through, Factory Reset
• Languages: English, French, Italian, German, Spanish, Simplified Chinese, Traditional Chinese, Japanese
• Lock for: OSD, Power
• I/O ports
• USB Type-C port
• speakers
• 2 x 2W internal stereo speakers
• Video
• USB Type-C port
• Input frequency range of the horizontal sync signal: 30-82 kHz
• Input frequency range of the vertical sync signal (frame rate): 60 Hz
• Performance
• Power supply compatible via USB Type-C port
• power consumption (typical)
• ON (Typical - 100% brightness): 8 W
• STANDBY: 0.8 W
• OFF: 0.15 W
• Monitor dimensions (without stand)
• Without VESA adapter: 14.16" x 8.61" x 0.59" / 359.73 mm x 218.82 mm x 14.97 mm
• With VESA adapter: 14.16" x 8.61" x 0 .79" / 359.73mm x 218.82mm x 19.97mm
• shipping dimensions
• 17.01" x 3.66" x 11.61" / 432mm x 93mm x 295mm
• Weight (without packaging)
• 2.45 lbs / 1.11 kg
• Weight (with packaging)
• 4.21 lbs / 1.91 kg
• operating temperature
• 0°C to 40°C / 32°F to 104°F
• storage temperature
• -20°C to 60°C / -4°F to 140°F
• moisture
• Operating: 20% to 80%
• Storage: 10% to 95% (38.7? max. wet bulb thermometer temperature)
• MTBF
• 50,000 hours, proven
• mounting options
• VESA via 4-hole 75mm mounting adapter on the back of the unit.
• Additional features
• Energy Star 8.0 TUV
• TÜV Rheinland (blue light filter)
• Power collection function via DDCCI
• impact protection
• IK07
• Included in delivery
• Touchscreen Monitor
• Quick Installation Guide (QIG)
• USB Type-C cable
• 75mm VESA adapter (assembled)

Garancia fogyasztók részére

• 2 év kötelező jótállás (gyártó által biztosított szervizgarancia)

Garancia nem fogyasztók részére

• 1 év gyártó által biztosított szervizgarancia
