MIKROTIK HAP AX S ROUTER, 802.11AX, 5X GIGABIT RJ45 PORT, 1XSFP 2.5G, 1XPOE KI

• Specifications

• Architecture
• ARM 32bit
• CPU
• EN7562CT
• CPU core count
• 2
• CPU nominal frequency
• 950 MHz
• CPU Threads count
• 2
• Switch chip model
• EN7523
• RouterOS license
• 4
• Operating System
• RouterOS v7
• Size of RAM
• 512 MB
• Storage size
• 128 MB
• Storage type
• NAND
• MTBF
• Approximately 100'000 hours at 25C
• Tested ambient temperature
• -40°C to 70°C

• Wireless capabilities

• Wireless 2.4 GHz Max data rate
• 574 Mbit/s
• Wireless 2.4 GHz Number of chains
• 2
• Wireless 2.4 GHz standards
• 802.11b/g/n/ax
• Antenna gain dBi for 2.4 GHz
• 5.5
• Wireless 2.4 GHz chip model
• MT7916
• Wireless 2.4 GHz generation
• Wi-Fi 6
• Wireless 5 GHz Max data rate
• 1800 Mbit/s
• Wireless 5 GHz Number of chains
• 3
• Wireless 5 GHz standards
• 802.11a/n/ac/ax
• Antenna gain dBi for 5 GHz
• 8.07
• Wireless 5 GHz chip model
• MT7976
• Wireless 5 GHz generation
• Wi-Fi 6
• WiFi speed
• AX2400

• Ethernet

• 10/100/1000 Ethernet ports
• 5
• Number of 1G Ethernet ports with PoE-out
• 1

• Fiber

• SFP ports
• 1 (2.5G supported)

• Peripherals

• Number of USB ports
• 1
• USB Power Reset
• Yes
• USB slot type
• USB type A
• Max USB current (A)
• 1

• Powering

• Number of DC inputs
• 2 (DC jack, PoE-IN)
• DC jack input Voltage
• 12-28 V
• Max power consumption
• 34 W
• Max power consumption without attachments
• 11 W
• PoE in
• Passive PoE
• Cooling type
• Passive
• PoE in input Voltage
• 18-28 V

• PoE-out

• PoE-out ports
• Ether5
• PoE out
• Passive PoE
• Low voltage PoE-Out current limit
• 0.6 A
• Max total out (A)
• 0.6 A
• Total output current
• 0.6
• Total output power
• 16.8

• Other

• CPU temperature monitor
• Yes

• Included parts

• 24V 1.5A power adapter
