ELO TOUCH 1790L TOUCHPRO PCAP ÉRINTŐKÉPERNYŐS MONITOR

Kijelző

• Képátló: 17"
  Felbontás: 1280x1024
  Panel:
  Képarány: 5:4

Csatlakozók

• • 1x VGA
  • 0x DVI
  • 1x DisplayPort
  • 1x HDMI
  • TV-tuner

• Specification

• Enclosure Color
• Black
• Touch Technology & Capacity
• 5-Wire Resistive (AccuTouch©) - Single-Touch
• SAW (IntelliTouch© Surface Acoustic Wave) - Single Touch
• PCAP (TouchPro© Projected Capacitive) - 10 Touch
• SAW (SecureTouch© Surface Acoustic Wave) - Single Touch
• Touch Interface
• TouchPro PCAP - USB 2.0
• AccuTouch, IntelliTouch, SecureTouch - Dual serial/USB 2.0
• Diagonal Size
• 17'' diagonal, Active matrix TFT LCD (LED)
• On Screen Display
• Accessible through switches on the unit's tethered OSD Control box.
• Controls: Menu, Up, Down, Select, Power
• Settings: Brightness, Contrast, Clock, Phase, H-position, V-position, Auto-Adjust, Sharpness, Color Temperature, OSD Timeout, OSD Language, OSD H-Position, OSD V-Position, Recall Defaults, Video Priority, Information, Touch On Sleep Mode, Touch Thru
• Languages: English, French, Italian, German, Spanish, Simplified Chinese, Traditional Chinese, Japanese
• Lockouts: OSD, Power
• Aspect Ratio
• 5:4
• Active Area
• 13.3" x 10.6"/ 337.92mm x 270.336mm
• Resolution
• 1280 x 1024
• Other Supported Resolutions
• 640 x 480 60Hz
• 720 x 400 70Hz
• 800 x 500, 60Hz
• 800 x 600 56, 60Hz
• 1024 x 768 60Hz
• 1280 x 800 60Hz
• 1280 x 1024 60Hz
• Viewing Angle
• Horizontal: +/-85° or 170° total / Vertical: +/-80° or 160° total
• Number of Colors
• 16.7 million
• Brightness (typical)
• LCD panel: 250 nits
• IntelliTouch: 225 nits
• AccuTouch: 200 nits
• SecureTouch: 220 nits
• TouchPro PCAP: 225 nits
• Response Time-total (typical)
• 5 msec
• Contrast Ratio
• 1000:1
• Input Video Format
• HDMI V1.3 Type A receptacle for HDMI input
• Analog VGA on Female DB-15 connector
• DisplayPort V1.1a - Supports later versions of Display Port video input
• Input Video Frequency
• Horizontal: 30 - 82 KHz
• Vertical: 50 - 75 Hz
• Video Interface
• HDMI, VGA & Display Port
• Power Supply
• External DC - Optional power brick (sold separately)
• Input power connector (Monitor)
• Coaxial power jack (2.0mm (+0.0 -0.1mm) pin outer diameter, 6.4mm (+/- 0.3mm) barrel inner diameter, 8.8mm (+/- 0.3mm) barrel depth)
• Input Voltage
• 12VDC +/- 5%
• Adapter Output Power Connector
• DC barrel plug (2.1mm (+/- 0.1mm) pin inner diameter, 5.5mm (+/- 0.05mm) barrel outer diameter, 9.5mm (+/- 0.3mm) barrel length)
• Power Consumption (Typical)
• Monitor + Adapter
• ON (Default - 75% Brightness): 8.52 W
• ON (Typical - 100% Brightness): 9.90 W
• SLEEP: 1.5 W
• OFF: 0.5W
• Dimensions
• Bezel: 14.50" x 12.06" x 1.87" / 368.4mm x 306.4mm x 47.5mm
• Zero-Bezel: 15.44" x 12.93" x 1.69" / 392.2mm x 327.5mm x 42.8mm
• Shipping Box Dimensions
• 18.74" x 16.46" x 7.21" / 476mm x 418mm x 183mm
• Weight (Unpackaged)
• 7.94 lbs / 3.6 Kg
• Weight (Packaged)
• 12.35 lbs / 5.6 Kg
• Operating Temperature
• 0°C to 40°C / 32°F to 104°F
• Storage Temperature
• -20°C to 60°C / -4°F to 140°F
• Humidity
• Operating: 20% to 80%
• Storage: 10% to 95%
• Sealability
• Touchscreen sealed to bezel
• Touchscreen sealed to LCD
• MTBF
• 50,000 hours demonstrated
• What's in the Box
• HDMI cable
• VGA Cable
• RJ45 OSD Remote
• Touch USB Cable
• Quick Install Guide
• For Zero-Bezel Models: Flush Mount Brackets w/Screws
• For Bezeled: IT/ST/AT Models: "L" (Side Mount) Brackets and w/Screws
• EEI Label
• Japan Class-B TM info sheet

Garancia fogyasztók részére

• 3 év kötelező jótállás (gyártó által biztosított szervizgarancia)

Garancia nem fogyasztók részére

• 2 év gyártó által biztosított szervizgarancia
