DLINK DGS-1100-26MPV2/E SWITCH 24X1000MBPS (24XPOE) + 2XGIGABIT KOMBÓ SFP FÉMHÁZAS MENEDZSELHETŐ RACKES

• Specifications

• 1000Base-T PoE Interface
• 24
• Auto MDI/MDIX
• Yes
• 10/100/1000BASE-T PoE ports
• 24
• 10/100/1000BASE-T/SFP Combo ports
• 2
• Switch Capacity
• 52 Gbps
• Max. Packet Forwarding Rate
• 38.69 Mpps
• Comply with RoHS 6
• Yes
• Energy Efficiency Ethernet (EEE)
• Yes
• Power Saving By Link Status
• Yes
• Power Saving By LED Shut-Off
• Yes
• Power Saving By Port Shut-Off
• Yes
• Power Saving By System Hibernation
• Yes
• Time-based PoE
• Yes
• Maximum PoE Budget
• 370W
• PoE Budget
• 370 W (30 W max. per PoE port)
• MAC Address Table Size
• 8K
• 802.3x Flow Control
• Yes
• Head-of-line (HOL) Blocking Prevention
• Yes
• 802.1D Spanning Tree (STP)
• Yes
• 802.1w Rapid Spanning Tree (RSTP)
• Yes
• 802.1AX Link Aggregation
• Yes
• 802.3ad Link Aggregation
• Yes
• Link Aggregation Group Per Device
• 13
• Max Port Per Link Aggregation Group
• 8
• Port Mirroring
• Yes
• Jumbo Frame
• 9216Byte
• Loopback Detection (LBD)
• Yes
• IGMP Snooping
• Yes
• Max IGMP Snooping Groups
• 64
• 802.1Q VLAN
• Yes
• Port-based VLAN
• Yes
• Voice VLAN
• Yes
• Auto Surveillance VLAN
• Yes(2.0)
• Asymmetric VLAN
• Yes
• Provider Backbone Bridge (PBB)
• Yes
• Number of Queue
• 8
• Class of Service (CoS)
• Yes
• Strict Priority Queue (SPQ)
• Yes
• Weighted Round Robin (WRR)
• Yes
• Deficit Round Robin (DRR)
• Yes
• Time based QoS
• Yes
• Port-based Bandwidth Control
• Yes
• SSL
• Yes
• Broadcast/Multicast/Unicast Storm Control
• Yes
• Traffic Segmentation
• Yes
• D-Link Safeguard Engine
• Yes
• DoS Attack Prevention
• Yes
• Cable Diagnostics
• Yes
• Simple Network Time Protocol (SNTP)
• Yes
• Web-based GUI
• Yes
• SNMP
• Yes
• SNMP Trap
• Yes
• TFTP Client
• Yes
• System Log
• Yes
• LLDP
• Yes
• D-Link Discover Protocol (DDP)
• Yes
• DHCP/BootP Client
• Yes
• Dual Images
• Yes
• Ping
• Yes
• D-Link Network Assistant
• Yes
• Smart Wizard
• Yes
• Store-and-Forwarding
• Yes
• Dimension
• 440 x 285 x 43 mm
• Weight
• 3.83Kg
• Operation Temperature
• -10-55°C
• Storage Temperature
• -20-70°C
• Operation Humidity
• 0%-95% RH
• Storage Humidity
• 0%-95% RH
• Operating Altitude
• 2000 m
• Maximum Power Consumption
• 434.4 W (PoE on)
  23.58 W (PoE off)
• Maximum Heat Dissipation
• 1470.46 BTU/hr
• Acoustic
• 53.7 dB(A)
• MTBF
• 269,137 hours
• Power Input
• AC: 100-240V
• CPU Speed
• 400MHz
• DRAM Size
• 128MB DDR3
• Flash Memory Size
• 32MB
• Packet Buffer Size
• 4.1MBytes
• FAN
• Fan *2

Garancia fogyasztók részére

• 2 év kötelező jótállás + 3 év gyártó által biztosított szervizgarancia

Garancia nem fogyasztók részére

• 5 év gyártó által biztosított szervizgarancia
