MIKROTIK CRS418-8P-8G-2S+5AXQ2AXQ-RM RACKBE SZERELHETŐ POE SWITCH, 16X GBIT (8X POE OUT) RJ45, 2X10GBIT SFP+ PORT

• Specifications

• Architecture
• ARM 64bit
• CPU
• IPQ-8072A
• CPU core count
• 4
• CPU nominal frequency
• 2208 MHz
• CPU Threads count
• 4
• Switch chip model
• 98DX226S
• RouterOS license
• 5
• Operating System
• RouterOS v7
• Size of RAM
• 1 GB
• Storage size
• 128 MB
• Storage type
• NAND
• MTBF
• Approximately 200'000 hours at 25C
• Tested ambient temperature
• -20°C to 70°C

• Powering

• Number of AC inputs
• 2
• AC input range
• 100-240 V
• Number of PSU slots
• 2
• Frequency
• 50-60 Hz
• Max power consumption
• 227 W
• Max power consumption without attachments
• 43 W
• Cooling type
• 4 fans

• PoE-out

• PoE-out ports
• Ether9-Ether16
• PoE out
• 802.3af/at
• Low voltage PoE-Out current limit
• 1.1 A
• High voltage PoE-Out current limit
• 0.56 A
• Total output power
• 150 W

• Wireless specifications

• Wireless 2.4 GHz Max data rate
• 1148 Mbit/s
• Wireless 2.4 GHz Number of chains
• 4
• Wireless 2.4 GHz standards
• 802.11b/g/n/ax
• Antenna gain dBi for 2.4 GHz
• 5 dBi
• Wireless 2.4 GHz chip model
• QCN-5024
• Wireless 2.4 GHz generation
• Wi-Fi 6
• Wireless 5 GHz Max data rate
• 2400 Mbit/s
• Wireless 5 GHz Number of chains
• 4
• Wireless 5 GHz standards
• 802.11a/n/ac/ax
• Antenna gain dBi for 5 GHz
• 6 dBi
• Wireless 5 GHz chip model
• QCN-5054
• Wireless 5 GHz generation
• Wi-Fi 6

• Ethernet & Fiber

• 10/100/1000 Ethernet ports
• 17
• Number of 1G Ethernet ports with PoE-out
• 8
• SFP+ ports
• 2

• Peripherals & Other

• Serial console port
• RJ45
• Number of USB ports
• 1
• USB Power Reset
• Yes
• USB slot type
• USB 3.0 type A
• Max USB current
• 1 A
• Monitors
• CPU temperature monitor, Current Monitor, PCB temperature monitor, Voltage Monitor
• Mode button
• Yes

• Certification & Approvals

• Certification
• CE, FCC, IC, EAC, ROHS
• IP rating
• IP20

• Included parts

• IEC cord
• K-100 fastening set
• IEC cord

Garancia fogyasztók részére

• 2 év kötelező jótállás (gyártó által biztosított szervizgarancia)

Garancia nem fogyasztók részére

• 1 év gyártó által biztosított szervizgarancia
