STAR TSP143IIIU-230 BLOKKNYOMTAT (FEHÉR)

Funkciók

• • Másolás
  • Szkennelés
  • FAX
  • Duplex nyomtatás

Csatlakozók

• • USB
  • LAN
  • Wi-Fi
  • Párhuzamos port

Nyomtatási méret

Tálcák

• 1. tálca:
  2. tálca:

• Specification

• Printer Method
• Direct Line Thermal
• Print Speed
• 43 RPM (Receipts Per Minute)
• Printer Case Color
• Ultra White or Gray
• Models Available
• Auto-Cutter with Emergency tear bar on the front guide
• Print Resolution
• 203 dpi (8 dots per mm)
• Font Size
• 12 X 24
• Character Set
• ANK 95, 32 Int 128 Graphic plus Chinese, Japanese, Korean, Taiwanese
• International Code Pages
• Star Mode=48
• Bar Codes
• Extended barcode functionality - 9 versions / PDF 417, Maxicode Option
• Line Spacing
• 3 mm or 4 mm or programmable
• Top Margin
• 11 mm default
• Auto Cutter
• Guillotine (Partial Cut Only)
• Cover Open Sensor
• Yes
• Logo Store Capacity
• Unlimited
• Multiple Copy Support
• Supported through FuturePRNT Software
• Journal Capability
• Supported through FuturePRNT Software
• Label Support
• N/A
• Power Supply
• Internal with power cable supplied
• Drivers Available
• Windows 10, Windows 8.1, Windows© XP 32 Bit, Vista 32/64 Bit, Windows 7 32/64 Bit, Server 2008 32/64 Bit, XP Embedded, POSReady2009, OPOS™, JavaPOS™, USB Vendor Class, CUPS, Mac, Mac OS X, Linux™, StarPRNT SDK with support for iOS and Android
• Digitally Signed (WHQL)
• Yes
• Swappable Interfaces
• N/A
• Connectivity
• USB with 1.8 m cable included
• Emulation Modes
• Star Mode
• SDKs (Raster only)
• Peripheral Drive Circuit
• 2 circuits, (24V max. 1A), 1 compulsion input
• Power Consumption
• Average 1.6 Amp. Printing, 0.1 Amp. Standby
• Operating Conditions
• Temperature: 5oC to 45oC
• Humidity: 10% - 90% RH (without condensation)
• Storage Conditions
• Temperature: -20oC to 60oC
• Humidity: 10% - 90% RH
• Dimensions
• 142 X 132 X 204 (w x h x d)mm
• Weight
• 1.72kg
• Reliability MCBF
• 60 Million Lines
• Printhead: 100km
• Auto Cutter: 2 Million Cuts

• Paper Specifications

• Width
• 80mm standard, 58mm with paper guide
• Thickness
• 0.053 ~ 0.085 mm
• Roll Diameter
• Up to 83 mm
• Easy - Load
• "Drop-In & Print"
• Paper Out Sensor
• Standard
• Paper Low Sensor
• N/A
• Maximum Print Width
• 80mm paper = 72mm, 58mm paper = 50.8mm

• What's in the Box

• Wall Mount Bracket
• 58mm Paper Guide
• 6ft Power Cable
• Power Switch Cover,
• Easy Setup Guide
• Installation CD with Drivers and FuturePRNT Receipt Design Software Auto Reverse Text Output Software (Power Cable not included with PUSB versions)
• Interface cables are included with the LAN and USB models

Garancia fogyasztók részére

• 2 év kötelező jótállás (gyártó által biztosított szervizgarancia)

Garancia nem fogyasztók részére

• 1 év gyártó által biztosított szervizgarancia
