DAHUA XVR5116HE-4KL-I2 XVR RÖGZÍTŐ (16 CSATORNA/H265+/8MP-7FPS/4MP-15FPS/2MP-25FPS/1X SATA/LITE AI PENTA-BRID)

• System

• Main Processor
• Embedded Processor
• Operating System
• Embedded LINUX

• Perimeter Protection

• Performance
• 2 channels, 10 IVS for each channel
• Object classification
• Human/Vehicle secondary recognition for tripwire and intrusion
• AI Search
• Search by target classification (Human, Vehicle)

• Face Recognition

• Performance
• Max 12 face pictures/sec processing
• 2 channels video stream face recognition, only support analog camera
• Stranger Mode
• Detect strangers' faces (not in device's face database). Similarity threshold can be set manually.
• AI Search
• Up to 8 target face images search at same time, similarity threshold can be set for each target face image.
• Database Management
• Up to 10 face databases with 20,000 face images in total. Name, gender, birthday, address, certificate type, cerificate No., countries©ions and state can be added to each face picture.
• Database Application
• Each database can be applied to video channels independently .
• Trigger Events
• Buzzer, Voice Prompts, Email, Snapshot, Recording, Alarm Out, PTZ Activation, etc.

• SMD Plus

• Performance
• 16 channels
• AI Search
• Search by target classification (Human, Vehicle)

• Video and Audio

• Analog Camera Input
• 16 channels, BNC
• HDCVI Camera Input
• 4K, 6MP, 5MP, 4MP, 1080P@25/30fps, 720P@50/60fps,
• 720P@25/30fps
• AHD Camera Input
• 4K, 5MP, 4MP, 3MP, 1080P@25/30, 720P@25/30fps
• TVI Camera Input
• 4K, 5MP, 4MP, 3MP, 1080P@25/30, 720P@25/30fps
• CVBS Camera Input
• PAL/NTSC
• IP Camera Input
• 16+16 channels, each channel up to 8MP
• Audio In/Out
• 16/1, RCA
• Two-way Talk
• Reuse audio in/out, RCA

• Recording

• Compression
• AI Coding/H.265+/H.265/H.264+/H.264
• Resolution
• 4K, 6MP, 5MP, 4K-N, 4MP, 3MP, 4M-N, 1080P, 720P, 960H, D1, CIF
• Record Rate
• Main stream: All channel 4K(1fps-7fps); 6MP(1fps-
• 10fps); 5MP(1fps-12fps); 4K-N, 4MP/3MP(1fps-15fps);
• 4M-N/1080P/720P/960H/D1/CIF (1fps-25/30fps);
• Sub steram:960H(1fps-15fps);
• D1/CIF(1fps-25/30fps)
• Bit Rate
• 32 Kbps-6144 Kbps Per Channel
• Record Mode
• Manual, Schedule (General, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop
• Record Interval
• 1 - 60 min (default: 60 min), Pre-record: 1 s-30 s, Post-record: 10 s-300 s
• Audio Compression
• G.711A, G.711U, PCM
• Audio Sample Rate
• 8 KHz, 16 bit Per Channel
• Audio Bit Rate
• 64 Kbps Per Channel

• Display

• Interface
• 1 HDMI ,1 VGA
• Resolution
• HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720
• VGA: 1920 × 1080, 1280 × 1024, 1280 × 720
• Multi-screen Display
• When IP extension mode not enabled: 1/4/8/9/16
• When IP extension mode enabled: 1/4/8/9/16/25/36
• OSD
• Camera title, Time, Video loss, Camera lock, Motion detection, Recording

• Network

• Interface
• 1 RJ-45 Port (1000 MB)
• Network Function
• HTTP, HTTPS, TCP/IP, IPv4/IPv6, Wi-Fi, 3G/4G, SNMP, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Server, P2P,IP Search (Supports Dahua IP camera, DVR, NVS, etc.)
• Max. User Access
• 128 users
• Smart Phone
• iPhone, iPad, Android
• Interoperability
• ONVIF 16.12, CGI Conformant

• Video Detection and Alarm

• Trigger Events
• Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips
• Video Detection
• Motion Detection, MD Zones: 396 (22 × 18), Video Loss, Tampering and Diagnosis
• Alarm input
• 16
• Relay Output
• 3

• Playback and Backup

• Playback
• 1/4/9/16
• Search Mode
• Time /Date, Alarm, MD and Exact Search (accurate to second)
• Playback Function
• Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom
• Backup Mode
• USB Device/Network

• Storage

• Internal HDD
• 1 SATA Port, up to 10TB capacity
• eSATA
• N/A

• Auxiliary Interface

• USB
• 2 USB Ports (1 USB 2.0 , 1 USB 3.0)
• RS485
• 1 Port, for PTZ Control
• RS232
• N/A

• Electrical

• Power Supply
• DC 12V/3A
• Power Consumption (Without HDD)
• <15W

• Construction

• Dimensions
• Mini 1U, 325 mm × 257 mm × 55 mm
• (12.80'' × 10.11'' × 2.17'')
• Net Weight (without HDD)
• 1.5 kg (3.3 lb)
• Gross Weight
• 2.3 kg (5.1 lb)
• Installation
• Desktop installation

• Environmental

• Operating Conditions
• -10°C to +55°C (+14°F to +131°F), 0-90% RH
• Storage Conditions
• -20°C to +70°C (-4°F to +158°F) , 0-90% RH

• Third-party Support

• Third-party Support
• Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, and more

• Certifications

• Certifications
• FCC: Part 15 Subpart B
• CE: CE-LVD: EN 60950-1/IEC 60950-1
• CE-EMC: EN 61000-3-2, EN 61000-3-3, EN 55032, EN 50130, EN 55024
