UBIQUITI WAVE-LR 60GHZ/5GHZ WI-FI 6 802.11AX BACKUP UISP PONT-MULTIPONT WAVE LONG-RANGE KLIENS

• Mechanical

• Dimensions
• O424.4 x 166.2 mm (O16.7 x 6.5")
• Weight
• Without mount: 2.59 kg (5.7 lb)
• With mount: 3.79 kg (8.4 lb)
• Enclosure material
• UV stabilized plastic
• Mount material
• Galvanized steel
• Pole mount diameter
• 25 to 76.2 mm (1 to 3") on pipe outer diameter
• Wind loading
• 286 N at 200 km/h (64.3 lbf at 125 mph)
• Weatherproofing
• IPX6

• Hardware

• Processor
• Dual ARM© Cortex©-A53 cores at 1 GHz
• Memory
• DDR3L 512 MB
• Networking interface
• (1) GbE RJ45 port
• Max. power consumption
• 18W
• Power method
• 48V DC passive PoE 4-pairs (1, 2+; 3, 6-) (4,5+; 7, 8-) or 2-pairs (4, 5+; 7, 8-)
• 24V DC passive PoE 4-pairs (1, 2+; 3, 6-) (4, 5+; 7, 8-)
• Power supply
• 48V DC, 0.65A gigabit PoE adapter (included)
• Can be powered by a UISP Router or UISP Switch
• Button
• Factory reset
• LEDs
• Power, Ethernet, GPS, link
• Operating temperature
• -40 to 60° C (-40 to 140° F)
• Operating humidity
• 5 to 95% noncondensing
• Certifications
• FCC, IC, CE

• Software

• OS
• airOS©
• Operating mode
• PtMP station
• Ubiquiti specific features
• Integrated 60 GHz radio, discovery protocol, Wave technology
• Services
• UISP, ping watchdog, NTP client, SNMP
• Tools
• Antenna alignment, discovery utility, ping, trace route, speed test
• Network
• Bridge/Router mode
• Software management
• Bluetooth management for easy setup over UISP app WEB UI
• Minimum software requirements
• Any modern web browser/iOS or Android™ based smartphone

• System

• Total throughput
• 2 Gbps (1 Gbps duplex)
• Maximum range
• 8+ km
• Encryption
• WPA2-PSK (AES)

• RF

• Operating frequency*
• 57 to 71 GHz
• *Depends on regulatory region.
• GPS
• Yes
• Channel bandwidth
• 2160, 1080 MHz
• Operating channels*
• 58320, 59400, 60480, 61560, 62640, 63720, 64800, 65880, 66960, 68040, 69120, 70200 MHz
• *Depends on regulatory region.
• Modulation
• 16QAM, QPSK
• Antenna gain
• 46 dBi
• Azimuth and elevation beamwidth
• 3 dB: 0.8°
• 6 dB: 1.1°

• Back-Up RF

• Operating frequency*
• U-NII-1 5150 - 5250 MHz
• US/CA
• U-NII-3 5725 - 5850 MHz
• Worldwide
• 5150 - 5875 MHz
• *Depends on regulatory region.
• Channel bandwidth
• 20, 40, 80 MHz
• Modulation
• BPSK (1?2), QPSK (1?2), QPSK (3?4), 16QAM (1?2), 16QAM (3?4), 64QAM (2?3), 64QAM (3?4), 64QAM (5?6), 256QAM (3?4), 256QAM (5?6), 1024QAM (3?4), 1024QAM (5?6)
• Antenna gain
• 22 dBi
• Polarization
• Dual-linear
• Cross-pol isolation
• 20 dB
• Azimuth and elevation beamwidth
• 3 dB: 8 to 10°

• LEDs

• Power
• Flashing white: bootup in progress
• White: not connected to UISP application
• Blue: connected to UISP application
• Flashing blue: locate in progress
• Blue/white: firmware upgrade in progress
• Ethernet
• Flashing blue: Ethernet traffic detected
• GPS
• Blue: receiving at least (4) GPS satellite signal
• Links
• White: 5GHz link
• Blue: 60GHz link
