MIKROTIK WAP AX LTE7 KIT

• Specifications

• Architecture
• ARM 32bit
• CPU
• IPQ-5010
• CPU core count
• 2
• CPU nominal frequency
• 800 MHz
• CPU Threads count
• 2
• RouterOS license
• 4
• Operating System
• RouterOS v7
• Size of RAM
• 256 MB
• Storage size
• 128 MB
• Storage type
• NAND
• MTBF
• Approximately 200'000 hours at 25C
• Tested ambient temperature
• -30°C to 70°C

• Powering

• Number of DC inputs
• 2 (DC jack, PoE-IN)
• DC jack input Voltage
• 12-57 V
• Max power consumption
• 13 W
• PoE in
• 802.3af/at
• Cooling type
• Passive
• PoE in input Voltage
• 18-57 V

• Mobile

• 3G Category
• R8 (DL: 42.2 Mbps; UL: 5.76 Mbps)
• 3G bands
• 1 (2100 MHz)
  3 (1800 MHz)
  5 (850 MHz)
  8 (900 MHz)
• LTE Category
• 7 (DL: 300 Mbps; UL: 100 Mbps)
• MIMO DL
• 2x2
• MIMO UL
• 1x1
• LTE FDD bands
• 1 (2100 MHz)
  3 (1800 MHz)
  5 (850 MHz)
  7 (2600 MHz)
  8 (900 MHz)
  20 (800 MHz)
  28 (700 MHz)
  32 (1500 MHz)
• LTE TDD bands
• 38 (2600 MHz)
  40 (2300 MHz)
  41 (2500 MHz)
• TAC
• 35312597

• Wireless specifications

• Wireless 2.4 GHz Max data rate
• 574 Mbit/s
• Wireless 2.4 GHz Number of chains
• 2
• Wireless 2.4 GHz standards
• 802.11b/g/n/ax
• Antenna gain dBi for 2.4 GHz
• 6.9
• Wireless 2.4 GHz chip model
• IPQ-5010
• Wireless 2.4 GHz generation
• Wi-Fi 6
• Wireless 5 GHz Max data rate
• 1200 Mbit/s
• Wireless 5 GHz Number of chains
• 2
• Wireless 5 GHz standards
• 802.11a/n/ac/ax
• Antenna gain dBi for 5 GHz
• 7
• Wireless 5 GHz chip model
• QCN-6102
• Wireless 5 GHz generation
• Wi-Fi 6

• Ethernet

• 10/100/1000 Ethernet ports
• 2

• Peripherals

• Number of SIM slots
• 1 Modem (Micro SIM)
• MiniPCI-e slots
• 1

• Other

• CPU temperature monitor
• Yes
• PCB temperature monitor
• Yes
• Voltage Monitor
• Yes

• Certification & Approvals

• Certification
• CE, EAC, ROHS
• IP
• 66

• Included parts

• 24V 0.8A power adapter
• Gigabit PoE injector
• Hose clamp 1
• K-95 kit
• Plastic tie strap
