IP-COM W36AP WALL ACCESS POINT WIFI AC1200 (300MBPS 2,4GHZ + 867MBPS 5GHZ; 1X1GBPS; 802.3AF POE)

• Product Information

• Product Model
• W36AP
• Product Appearance
• In-wall access point
• Product Dimension
• 86 x 86 x 32 mm
• Application Scenarios
• WiFi coverage for large-sized apartments/villas/hotel rooms

• Hardware Specifications

• Working Frequency Band
• 2.400 - 2.4835 GHz, 5.15 0 - 5.250 GHz
• Wireless Protocol Standard
• IEEE 802.11a/b/g/n/ac
• 2.4 GHz Access Rate
• 1-300Mbps
• 5 GHz Access Rate
• 6-867Mbps
• 2.4 GHz Maximum Connections
• 128
• 5 GHz Maximum Connections
• 128
• Ethernet Port
• 2 10/100/1000 Base TX ports
• Reset Button
• 1 reset button
• LED Indicators
• 1 x SYS LED indicator and 1 x LAN LED indicator
• Power Consumption of the Whole Device
• Full load 7.8 W
• Power Supply Mode
• IEEE 802.3af
• 2.4 GHz Antenna Gain
• 4 dBi
• 5 GHz Antenna Gain
• 4 dBi
• 2.4 GHz Output Power
• 20+/-1.5 dBm
• 5 GHz Output Power
• 16+/-1.5 dBm
• 11b 1 Mbps Received Sensitivity
• -95 dBm
• 11n MCS7 Received Sensitivity
• -73 dBm
• 11a 6 Mbps Received Sensitivity
• -93 dBm
• 11ac MCS7 Received Sensitivity
• -75 dBm

• Software Specifications

• Operating Mode
• AP, Client + AP
• SSID Hide
• Supported
• 2.4 GHz SSID Number
• 8
• 5 GHz SSID Number
• 4
• Chinese SSID
• Supported
• WEP
• 64/128 bit encryption supported
• WPA-PSK
• AES/TKIP
• WPA2-PSK
• AES/TKIP
• WPA
• Supported
• WPA2
• Supported
• Wireless Access Control
• MAC address-based filtering supported
• TX Power Adjustment
• Supported
• SSID Isolation
• Supported
• AP Isolation
• Supported
• Wireless User Access Limit
• Supported
• Weak Signal Client Access Limit
• Supported
• WMM
• Supported
• 5 GHz Band Navigation (5 GHz Priority)
• Supported
• Multicast to Unicast
• Supported
• Detection Broadcast Message Reply Inhibition
• Supported
• Access Control
• Supported
• VLAN and SSID Binding
• Supported
• LED Control
• Supported
• Diagnostic Tool
• ping
• Timed Reboot
• Supported
• Cyclic Reboot
• Supported
• Device Management
• Web management
• Uplink Detection
• Supported
• Hardware Watchdog
• Supported
• Remote Log Management
• Supported
• Logs
• System log
• Firmware Upgrade
• Local upgrade and upgraded by AC
• Reboot
• Local reboot and rebooted by AC
• Reset
• Local reset and reset by AC
• Backup
• Supported
• Restore
• Supported
• AC Management
• AC1000/AC2000/AC3000 supported

• Working Environment

• Default Login IP Address
• 192.168.0.254
• Default User Name
• admin
• Operating Temperature
• -10°C to 45°C
• Operating Humidity
• 10% - 90% RH (non-condensing)
• Storage Temperature
• -30°C to 70°C
• Storage Humidity
• 10% - 90% RH (non-condensing)
