TP-LINK VIGI C330 (6MM) IP KAMERA KÜLTÉRI ÉJJELLÁTÓ 3 MEGAPIXEL, 6MM OBJEKTÍV

TP-LINK VIGI C330 (6MM) IP Kamera kültéri éjjellátó 3 Megapixel, 6mm Objektív

Biztonságtechnika > IP kamera

nem elérhető




  • mysoft azonosító
    0-2964085
Adatlap frissítve: 2026. 10. 20. 16:48:35


  • KAMERA

  • Képérzékelő
  • 1/2.8" Progressive Scan CMOS
  • Shutter Speed
  • 1/3 to 1/10000 s
  • Slow Shutter
  • Yes
  • Min. szükséges megvilágítás
  • Color: 0.1 Lux; 0 Lux with IR
  • Day/Night Mechanism
  • IR Cut Filter
  • Day/Night Switch
  • Day/Night/Auto/Schedule-Switch
  • Optika
  • 6 mm
  • Aperture
  • 6 mm: F2.0
  • Lens Mount
  • M12
  • Látószög
  • 6mm: 51.9°/28.7°/60°(H/V/D)
  • IR Working Distance
  • 30m
  • Weatherproof Rating
  • IP67
  • Digital Noise Reduction
  • 3D DNR
  • WDR
  • DWDR
  • LENS

  • Type
  • Fixed Focal Lens
  • Focal Length
  • 6 mm
  • Aperture
  • 6mm: F2.0
  • FOV
  • 6 mm:
  • Horizontal FOV: 51.9°, Vertical FOV: 28.7°, Diagonal FOV: 60°
  • Lens Mount
  • M12
  • DORI Distance
  • 6 mm:
  • Detect: 98 m (321 ft)
  • Observe: 41 m (134 ft)
  • Recognize: 20 m (64 ft)
  • Identify: 10 m (32 ft)
  • VIDEO

  • Max. Resolution
  • 2304 × 1296
  • Main Stream
  • Frame Rate:
  • 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
  • 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
  • Resolution:
  • 2304x1296, 2048x1280, 1920x1080, 1280x720
  • Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps.
  • Sub-Stream
  • Frame Rate:
  • 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
  • 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
  • Resolution:
  • 704x576, 640x480, 352x288, 320x240
  • Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps.
  • Bit Rate Control
  • CBR, VBR
  • Video Compression
  • Main Stream: H.265+/H.265/H.264+/H.264
  • Sub-Stream: H.265/H.264
  • H.264 Type
  • Main Profile/High Profile
  • H.264+
  • Main Stream Supported
  • H.265 Type
  • Main Profile
  • H.265+
  • Main Stream Supported
  • Video Bit Rate
  • Main Stream: 256 Kbps to 4 Mbps
  • Sub-Stream: 64 Kbps to 512 Kbps
  • ILLUMINATOR

  • IR LED
  • Quantity: 2
  • Range: 30m
  • Wavelength: 850nm
  • White LED
  • N/A
  • Illuminator On/Off Control
  • Auto/Scheduled/Always on/Always off
  • ANGLE ADJUSTMENT (MANUAL)

  • Range
  • Pan: -90° to 90°
  • Tilt: -90° to 90°
  • IMAGE

  • Image Settings
  • Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, White Balance, Prevent Overexposure to Infrared Light, HLC Adjustable by Client Software, Rotation(90°/270°)
  • Image Enhancement
  • BLC/3D DNR/HLC/SmartIR
  • Wide Dynamic Range
  • DWDR
  • SNR
  • > 52 dB
  • Image Parameters Switch
  • Yes
  • Privacy Mask
  • Up to 4 Masks
  • ROI
  • 1 Region
  • OSD Setting
  • Yes
  • HANG

  • Hangkommunikáció
  • N/A
  • Hangbemenet
  • N/A
  • Hangkimenet
  • N/A
  • Hangtömörítés
  • N/A
  • Audio Sampling Rate
  • N/A
  • Environment Noise Filtering
  • N/A
  • Audio Bit Rate
  • N/A
  • HÁLÓZAT

  • Biztonság
  • Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication
  • Network Storage
  • NAS (NFS, SMB/ CIFS)
  • Szabvány
  • TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS
  • API
  • ONVIF
  • Simultaneous Live View
  • 3 Main Streams & 3 Sub-Streams
  • Client
  • VIGI App, VIGI Security Manager, VIGI NVR, Web
  • Web Browser
  • Google Chrome 57 and above
  • Firefox 52 and above
  • Safari 11 and above
  • Microsoft Edge 91 and above
  • Cloud
  • Yes
  • ONVIF
  • Yes
  • FIZIKAI KEZELŐFELÜLET

  • Hálózati csatlakozás
  • 1 RJ45 10/100M Self-Adaptive Ethernet Port
  • Alarm
  • N/A
  • Reset Button
  • N/A
  • Power
  • DC Power Port
  • Gomb
  • -
  • Video Output
  • -
  • On-board Storage
  • N/A
  • Built-in Microphone
  • N/A
  • Built-in Speaker
  • N/A
  • Audio
  • N/A
  • FIGYELMEZTETÉSI ÉS ESEMÉNYKEZELÉSI VEZÉRLÉS

  • Smart Event
  • Human & Vehicle Classification, Area Intrusion Detection, Line-Crossing Detection, People Detection, Vehicle Detection, Region Entering Detection, Region Exiting Detection, Object Abandoned Detection, Object Removal Detection
  • Basic Event
  • Motion Detection, Video Tampering Detection, Exception ( Illegal Login)
  • Alarm Linkage
  • Message Push
  • Linkage Method
  • N/A
  • Output Notification
  • Message Push
  • ÁLTALÁNOS

  • Csomagolás tartalma
  • VIGI Network Camera
  • Quick Start Guide
  • Waterproof Cable Attachments
  • Mounting Accessories
  • Operating Temperature
  • -30-60 °C
  • Storage Temperature
  • -40-60 °C
  • Storage Humidity
  • 95% or Less (Non-Condensing)
  • Operating Humidity
  • 95% or Less (Non-Condensing)
  • Méret (Ma x Sz x Mé)
  • 174 × 74 × 71 mm
  • Material
  • Plastic
  • General Features
  • Two Streams, Mirror, Privacy Masks, Password Reset via E-mail, HTTP Listening
  • Net Weight
  • 0.2 Kg
  • Gross Weight
  • 0.35 Kg
  • Power Consumption
  • 12V DC: Max 5W
  • PoE: Class 0
  • Power Supply
  • 12V DC +/- 5%, 5.5mm Coaxial Power Plug
  • PoE (802.3af/at, class 0)
  • Protection
  • IP67
  • Product Dimensions (L x W x H)
  • 174 × 74 × 71 mm
  • Certifications
  • CE/BSMI/VCCI/ONVIF
  • VIDEÓ/KÉP

  • Videó tömörítés
  • Main Stream: H.265+/H.265/H.264+/H.264
  • Sub-Stream: H.265/H.264
  • Kép frissítés (frame) és felbontás
  • Main Stream:
  • Frame Rate: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
  • Resolution: 2304x1296, 2048x1280, 1920x1080, 1280x720
  • Sub-Stream:
  • Frame Rate: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
  • Resolution: 704x576, 640x480, 352x288, 320x240
  • Max. Resolution
  • 3MP (2304 × 1296)
  • Videótovábbítás
  • Main Stream
  • Sub-Stream
  • Képbeállítás
  • Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, White Balance Adjustable by Client Software, Rotation(90°/270°)
  • Image Enhancement
  • BLC/3D DNR/HLC/SmartIR
  • Video Bit Rate
  • 64 Kbps to 4 Mbps
  • Day/Night Switch
  • Day/Night/Auto/Schedule
  • SMART FEATURE-SET

  • Smart Event
  • Human & Vehicle Classification, Area Intrusion Detection, Line-Crossing Detection, People Detection, Area Entrance Detection, Area Exiting Detection, Abandoned Object Detection, Object Removal Detection, Vehicle Detection
  • Basic Event
  • Motion Detection, Camera Tampering Detection, Exception (Illegal Login)
  • Linkage Method
  • Trigger Notification: ONVIF, HTTPS
  • Region of Interest
  • 1 Region
Garancia fogyasztók részére
  • 2 év kötelező jótállás + 1 év gyártó által biztosított szervizgarancia
Garancia nem fogyasztók részére
  • 3 év gyártó által biztosított szervizgarancia
