UBIQUITI PRO XG AGGREGATION

• Overview

• Dimensions
• 442.4 x 43.7 x 480 mm (17.4 x 1.7 x 18.9")
• Port Layout
• 25G SFP28
• 32 (25G/10G/1G)
• Redundancy
• DC Power Backup
• Layer 3
• Yes
• Form Factor
• Rack Mount (1U)
• Etherlighting
• Yes

• Performance

• Switching Capacity
• 1.6 Tbps
• Total Non-Blocking Throughput
• 800 Gbps
• Forwarding Rate
• 1.2 Bpps
• Supported VLANs
• 1,000
• MAC Address Table Size
• 32,000
• IPv4 Static Routes
• 512
• Packet Buffer Size
• 8 MB
• Access Lists
• IPv4
• 256
• MAC
• 256

• Layer 3 Features

• DHCP Server (Local Networks)
• DHCP Relay
• Inter-VLAN Routing (Local Networks)
• Static Routing (Local Networks)

• Layer 2 Features

• LACP Port Aggregation
• STP & RSTP
• Advanced IGMP Configuration (Querier, Fast Leave, Router Port)
• IGMP Snooping
• 802.1X Control
• MAC-Based ACLs & Device Isolation
• DHCP Snooping & Guarding
• Egress Rate Limit
• Flow Control
• Storm Control
• Multicast & Broadcast Rate Limiting
• MAC Address Blocking
• IP-Based ACLs & Network Isolation
• MAC-Based Port Restriction
• Port Isolation
• Port Mirroring
• Jumbo Frames
• LLDP-MED
• Voice VLAN
• Loop Protection
• Virtual Network Override

• Hardware

• Max. Power Consumption
• 200W
• Power Method
• (1) Universal input, 100-240V AC, 50/60 Hz
• (1) USP RPS DC input
• Power Input Method
• AC input
• Power Supply
• AC/DC, internal, 200W
• Supported Voltage Range
• 100-240V AC
• Management
• Ethernet
• AR
• Heat Dissipation
• 682 BTU/hr
• Weight
• Without mounting bracket: 7.1 kg (15.7 lbs)
• With mounting bracket:7.2 kg (15.9 lbs)
• Enclosure Material
• SGCC steel
• Mount Material
• SGCC steel
• Supported Rack Depth
• 482.6 mm (19") four-post racks
• Posts depths ranging from 600 to 1,066 mm (23.6-42")
• LCM Display
• 1.3" touchscreen
• ESD Protection
• Air: +/- 12kV, contact: +/- 8kV
• Ambient Operating Temperature
• -5 to 40° C (23 to 104° F)
• Ambient Operating Humidity
• 10 to 90% noncondensing
• Etherlighting
• SFP28
• Yes
• LEDs
• RPS
• Yes
• NDAA Compliant
• Yes
• Certifications
• CE, FCC, IC, Anatel: 05977-25-08356
