UBIQUITI PRO XG 8 POE SWITCH, KOMPAKT ASZTALI/FALI, 8 PORT, L3 ETHERLIGHTINGT POE++, 8X 10 GBE, 2X 10G SFP+ PORT

• Overview

• Dimensions
• 210.4 x 173.8 x 43.7 mm (8.28 x 6.84 x 1.7")
• Port Layout
• 10 GbE RJ45
• 8 (All PoE++) (10G/5G/2.5G/1G/100M)
• 10G SFP+
• 2 (10G/1G)
• Max. PoE Output
• Up to PoE++
• Total PoE Availability
• 155W
• Layer 3
• Yes
• Form Factor
• Compact desktop, wall
• Etherlighting
• Yes

• Performance

• Switching Capacity
• 200 Gbps
• Total Non-Blocking Throughput
• 100 Gbps
• Forwarding Rate
• 149 Mpps
• Supported VLANs
• 1,000
• MAC Address Table Size
• 32,000
• L3 Table Size
• ARP Entries
• 12,000
• IPv4 Routes
• 12,000
• IPv4 Static Routes
• 256
• Packet Buffer Size
• 2 MB
• Access Lists
• IPv4
• 128
• MAC
• 128

• Layer 3 Features

• DHCP Server (Local Networks)
• DHCP Relay
• Inter-VLAN Routing (Local Networks)
• Static Routing (Local Networks)

• Layer 2 Features

• LACP Port Aggregation
• STP & RSTP
• QoS (DSCP)
• Pro AV Profiles (Play, Dante, Q-SYS, NDI, SDVoE, Shure, AES67, Crestron)
• Advanced IGMP Configuration (Querier, Fast Leave, Router Port)
• IGMP Snooping
• 802.1X Control
• MAC-Based ACLs & Device Isolation
• DHCP Snooping & Guarding
• Egress Rate Limit
• Flow Control
• Storm Control
• Multicast & Broadcast Rate Limiting
• MAC Address Blocking
• IP-Based ACLs & Network Isolation
• MAC-Based Port Restriction
• Port Isolation
• Port Mirroring
• Jumbo Frames
• LLDP-MED
• Voice VLAN
• Loop Protection
• Virtual Network Override

• Hardware

• PoE Ports
• PoE++
• 8
• Max. PoE Wattage per Port by PSE
• PoE
• 15.4W
• PoE+
• 30W
• PoE++
• 60W
• Max. Power Consumption
• 61W (Excluding PoE output)
• 210W (Including PoE output)
• Power Method
• AC/DC Adapter (included)
• Power Input Method
• DC input
• Power Supply
• AC/DC, external, 210W
• Supported Voltage Range
• 50-57V DC
• Management
• Ethernet
• Weight
• 1.6 kg (3.5 lb)
• Enclosure Material
• SGCC steel
• Mount Material
• Polycarbonate
• ESD Protection
• Air: +/- 30kV, contact: +/- 30kV
• Ambient Operating Temperature
• -5 to 45° C (23 to 113° F)
• Ambient Operating Humidity
• 10 to 90% noncondensing
• Etherlighting
• Ethernet
• SFP+
• LEDs
• System
• NDAA Compliant
• Yes
• Certifications
• CE, FCC, IC, Anatel: 04322-25-08356

• Software

• Application Requirements
• UniFi Network
• Version 9.0.114 and later

Garancia fogyasztók részére

• 2 év kötelező jótállás (gyártó által biztosított szervizgarancia)

Garancia nem fogyasztók részére

• 1 év gyártó által biztosított szervizgarancia
