UBIQUITI USW-PRO-MAX-48 32PORT GBE LAN 16X2.5GBE MULTI-GIGABIT LAN 4X SFP+ PORT L3 MENEDZSELHETŐ SWITCH

• Mechanical

• Dimensions
• 442 x 325 x 44 mm (17.4 x 12.8 x 1.7")
• Weight
• Without mounting brackets: 4.8 kg (10.6 lb)
• With mounting brackets: 4.9 kg (10.8 lb)
• Enclosure material
• SGCC steel

• Hardware

• Management interface
• Ethernet In-Band
• Networking interface
• (32) GbE RJ45 ports
• (16) 1/2.5 GbE RJ45 ports
• (4) 10G SFP+ ports
• Total non-blocking throughput
• 112 Gbps
• Switching capacity
• 224 Gbps
• Forwarding rate
• 166.656 Mpps
• Power method
• (1) Universal input, 100-240V AC, 50/60 Hz
• (1) USP-RPS DC input
• Power supply
• AC/DC, internal, 100W
• Supported voltage range
• 100-240V AC
• Max. power consumption
• 100W
• LCM display
• (1) 1.3" touchscreen
• Button
• Factory reset
• Ambient operating temperature
• -5 to 40° C (23 to 104° F)
• Ambient operating humidity
• 10 to 90% noncondensing
• Certifications
• CE, FCC, IC

• Switching Features

• Layer 2 features
• IGMP snooping
• STP / RSTP with priorities and port-level disable
• Port isolation
• Storm control
• Voice VLAN
• Port mirroring
• LACP port aggregation
• Multicast / broadcast rate limiting
• MAC address blocking
• Flow control
• 802.1X control
• Jumbo frames
• Proprietary loop protection
• DHCP snooping / guarding
• Egress rate limit
• LLDP-MED
• Port restricted by MAC
• Device isolation with ACLs
• Layer 3 features
• DHCP for locally-managed networks
• DHCP relay
• Inter-VLAN routing between networks on same switch
• Static routing between local networks
• Network isolation with ACLs

• Etherlighting

• Ethernet
• Locating
• Speed/link
• Native VLAN/network
• SFP+
• Locating
• Speed/link
• Native VLAN/network

• LEDs

• System
• Status
• RPS
• Status

• Application Requirements

• UniFi Network
• Version 8.0.24 and later

Garancia fogyasztók részére

• 3 év kötelező jótállás (gyártó által biztosított szervizgarancia)

Garancia nem fogyasztók részére

• 1 év gyártó által biztosított szervizgarancia
