UBIQUITI USW-FLEX-2.5G-8-POE UNIFI FLEX 8X2.5GBE MULTI-GIGABIT LAN 196W POE 1X SFP+ COMBO PORT SWITCH

• Overview

• Dimensions
• 212.9 x 99.4 x 33.5 mm (8.4 x 3.9 x 1.3")
• Port Layout
• 2.5 GbE RJ45
• 8 (All PoE++)
• (2.5G/1G/100M/10M)
• 10 GbE RJ45
• 1 (PoE+++)
• (10G/5G/2.5G/1G/100M)
• 10G SFP+
• 1
• Max. PoE Output
• Up to PoE++
• Total PoE Availability
• PoE+++ input: 76W
• PoE++ input: 46W
• PoE+ input: 16W
• 210W AC adapter input: 196W
• Form Factor
• Compact Desktop, wall, DIN, magnetic

• Performance

• Switching Capacity
• 60 Gbps
• Total Non-Blocking Throughput
• 30 Gbps
• Forwarding Rate
• 45 Mpps
• Supported VLANs
• 256
• MAC Address Table Size
• 4,000

• Layer 2 Features

• STP & RSTP
• Yes
• Egress Rate Limit
• Yes
• Flow Control
• Yes
• Storm Control
• Yes
• Multicast & Broadcast Rate Limiting
• Yes
• Port Isolation
• Yes
• Port Mirroring
• Yes
• Jumbo Frames
• Yes
• Loop Protection
• Yes

• Hardware

• PoE Ports
• PoE++
• 8
• Max. PoE Wattage per Port by PSE
• PoE
• 15.4W
• PoE+
• 32W
• PoE++
• 64W
• Max. Power Consumption
• 14W (Excluding PoE output) with PoE input
• 17W (Excluding PoE output) with AC adapter input
• 210W (Including PoE Output)
• Power Method
• (1) AC/DC adapter (Excluded)
• (1) PoE+++
• Power Input Method
• DC Input
• PoE
• Supported Voltage Range
• 50-57V DC/PoE
• Management
• Ethernet
• Weight
• 567 g (20 oz)
• Enclosure Material
• Polycarbonate
• Mount Material
• Polycarbonate
• Ambient Operating Temperature
• -20 to 45° C (-4 to 113° F)
• Ambient Operating Humidity
• 10 to 90% noncondensing
• Certifications
• CE, FCC, IC
• NDAA Compliant
• Yes

• Software

• Application Requirements
• UniFi Network
• Version 9.0.114 and later
