UBIQUITI ACCES POINT - UNIFI HD IN-WALL WAVE2, WI-FI

• Mechanical

• Dimensions
• 139.7 x 86.7 x 25.75 mm (5.5 x 3.41 x 1.01")
• Weight
• 210 g (7.41 oz)
• Networking Interface
• (5) 10/100/1000 Ethernet Ports
• Buttons
• Reset
• Power Method
• 802.3af PoE
• 802.3at PoE+
• Supported Voltage Range
• 44 to 57VDC
• Power Supply
• UniFi Switch (PoE)
• PoE Out
• 48V Passthrough (Pins +1, 2; -3, 6)
• Power Save
• Supported
• Beamforming
• Supported
• Maximum Power Consumption with PoE Passthrough
• 11W
• 23W (* Requires 802.3at PoE+ switch)
• TX Power
• 2.4 GHz
• 23 dBm
• 5 GHz
• 26 dBm
• Dual-Band Antennas
• (2) Single-Port, Single-Polarity Dual-Band Antennas, 2.4 GHz: 1.8 dBi Each, 5 GHz: 3.4 dBi Each
• Single-Band Antennas
• (2) Single-Port, Dual-Polarity, Single-Band Antennas, 5 GHz: 6 dBi Each
• Wi-Fi Standards
• 802.11 a/b/g/n/r/k/v/ac/ac-wave2
• Wireless Security
• WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES), 802.11w/PMF
• BSSID
• Up to 8 per Radio
• Mounting
• 1-Gang Electrical Wall Box (Not Included)
• Operating Temperature
• -10 to 60° C (14 to 140° F)
• Operating Humidity
• 5 to 95% Noncondensing
• Certifications
• CE, FCC, IC

• Advanced Traffic Management

• VLAN
• 802.1Q
• Advanced QoS
• Per-User Rate Limiting
• Guest Traffic Isolation
• Supported
• WMM
• Voice, Video, Best Effort, and Background
• Concurrent Clients
• 200+

• Supported Data Rates (Mbps)

• 802.11a
• 6, 9, 12, 18, 24, 36, 48, 54 Mbps
• 802.11n
• 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)
• 802.11ac
• 6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80)
• 58 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 160)
• 802.11b
• 1, 2, 5.5, 11 Mbps
• 802.11g
• 6, 9, 12, 18, 24, 36, 48, 54 Mbps

Garancia fogyasztók részére

• 1 év kötelező jótállás (gyártó által biztosított szervizgarancia)

Garancia nem fogyasztók részére

• 1 év gyártó által biztosított szervizgarancia
