UBIQUITI UNIFI ACCESS INTERCOM

• Overview

• Dimensions
• 324.8 x 113.7 x 28.3 mm (12.8 x 4.5 x 1.1")
• Integrated Camera
• Yes
• NFC Card & Keyfob Access
• Yes
• PIN Access
• Yes
• Mobile Unlock
• Yes
• Face Unlock
• Yes
• Two-Way Intercom & Doorbell Access
• Yes
• NDAA Compliant
• Yes
• UL 294 Level
• Destructive attack: Level I
• Line security: Level I
• Endurance: Level I
• Standby power: Level I
• Weatherproofing
• IP65

• Mechanical

• Weight
• Device: 965 g (2.1 lb)
• Bracket: 445 g (1 lb)
• Enclosure Material
• Aluminum alloy, UV-stabilized polycarbonate, glass
• Mount Material
• Powder-coated stainless steel
• Mounting
• Wall mount, adapter to the gooseneck pedestal (Included)
• Surface angle, flush mount, sunshield kit (Optional)

• Hardware

• Indoor and Outdoor Use
• Yes
• Networking Interface
• (1) GbE RJ45 port
• Connectivity
• BLE 4.2
• NFC
• Power Method
• PoE
• UL 294 Power-limited Class 2 PSU
• UL 60950-1/62368-1 LPS/PS2 PSU
• Max. Power Consumption
• 13W
• Supported Voltage Range
• 48V DC
• Video
• Max. Frame Rate
• 30 FPS
• Resolution
• 2MP 1200 x 1600 (3:4)
• Optics
• Resolution
• 8 MP (2448 × 3264)
• Field of View
• H: 79.4°, V: 97.5°, D: 118.2°
• Sensors
• Proximity sensor
• ALS sensor
• Display
• Size
• 177 mm (7") diagonal
• Screen Technology
• Capacitive multi-touch
• Luminance
• Max. 1000 nits (Typical)
• Screen Orientation
• Portrait
• Resolution
• 1024 x 600 px
• Microphone
• Yes
• Speaker
• Yes
• NFC Frequency
• 13.56 MHz
• NFC Read Range
• < 30 mm (1.18'')
• NFC Technology
• ISO/IEC 14443A / 14443B / 15693 / 18092 (Ecma 340)
• MIFARE Classic / MIFARE DESFIRE
• Sony FeliCa™ (ID only)
• NFC Forum tags T1T, T2T, T3T, T4T and T5T
• LEDs
• Amber
• Buttons
• (1) Factory reset
• PoE Cabling Requirements
• Cat 5e cabling is the minimum performance category recommended. The performance category utilized should match the transmission speed required at the installation site.
• The minimal conductor gauge permitted to connect between the PSE or power injector and the PD shall be 26 AWG (0.13 mm2 ) for patch cords; 24 AWG (0.21 mm2 ) for horizontal or riser cable.
• UL 294 Statement
• Compliance with IEEE 802.3 specifications was not verified as part of UL 294.
• The equipment is intended to comply with the section of the National Electrical Code, ANSI/NFPA 70, Article 725.121, Power Sources for Class 2 and Class 3 Circuits.
• CAN/ULC-60839-11-1 Grade
• Grade assignment: I
• Certifications
• CE, FCC, IC, UL 294, CAN/ULC-60839-11-1
• Document number, and issue date and/or revision level
• UA-Intercom, V01
• Ambient Operating Temperature
• Device: -30 to 60° C (-22 to 140° F)
• Display: -25 to 60° C (-13 to 140° F)
• Ambient Operating Humidity
• 5 to 90% noncondensing

• Software

• Management Application
• Access
• Software Information
• The software version can be checked at https://unifi.ui.com
