UBIQUITI UNIFI U7 PRO XG ACCESS POINT, 1X 10GBE RJ45, POE+, 802.11BE, DOBOZOS(WIFI 7, TÁP NÉLKÜL)

• Overview

• Dimensions
• 206 x 32.5 mm (8.1 x 1.3")
• WiFi Standard
• WiFi 7
• Spatial Streams
• 6
• Coverage Area
• 140 m2 (1,500 ft2)
• Max. Client Count
• 300+
• Uplink
• 10 GbE
• Mounting
• Ceiling, Wall
• (Lite Mount Included)
• Power Method
• PoE+

• Performance

• MIMO
• 6 GHz
• 2 x 2 (DL/UL MU-MIMO)
• 5 GHz
• 2 x 2 (DL/UL MU-MIMO)
• 2.4 GHz
• 2 x 2 (DL/UL MU-MIMO)
• Max. Data Rate
• 6 GHz
• 5.8 Gbps (BW320)
• 5 GHz
• 4.3 Gbps (BW240)
• 2.4 GHz
• 688 Mbps (BW40)
• Antenna Gain
• 6 GHz
• 6 dBi
• 5 GHz
• 5 dBi
• 2.4 GHz
• 4 dBi
• Max. TX Power
• 6 GHz
• 24 dBm
• 5 GHz
• 26 dBm
• 2.4 GHz
• 23 dBm
• Max. BSSIDs
• 8 per Radio
• Supported Data Rates
• 802.11be (WiFi 7)
• 6 GHz: 7.3 Mbps to 5.8 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/320)
• 5 GHz: 7.3 Mbps to 4.3 Gbps (MCS0 - MCS13 NSS1/2/3/4, EHT 20/40/80/160/240)
• 802.11ax (WiFi 6)
• 7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160)
• 802.11ac (WiFi 5)
• 6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160)
• 802.11n
• 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)

• Features

• Wireless Meshing
• Band Steering
• 802.11v BSS Transition Management
• 802.11r Fast Roaming
• 802.11k Radio Resource Management (RRM)
• Advanced Radio Management
• Passpoint (Hotspot 2.0)
• Captive Hotspot Portal
• Custom Branding Landing Page
• Voucher Authentication
• Payment-Based Authentication
• External Portal Server Support
• Password Authentication
• Guest Network Isolation
• Private Pre-Shared Key (PPSK)
• WiFi Speed Limiting
• Client Device Isolation
• WiFi Schedules
• RADIUS over TLS (RadSec)
• Dynamic RADIUS-assigned VLAN

• Hardware

• Max. Power Consumption
• 22W
• Supported Voltage Range
• 42.5-57V DC
• Networking Interface
• (1) 10 GbE RJ45 port
• Weight
• 750 g (1.7 lb)
• Management
• Ethernet
• Enclosure Material
• UV-stabilized polycarbonate, aluminum alloy
• Mount Material
• Stainless steel (SUS304), galvanized steel (SGCC)
• LEDs
• System
• White/Blue
• Channel Bandwidth
• HT 20/40, VHT 20/40/80/160, HE 20/40/80/160, EHT 20/40/80/160/240/320 (MHz)
• NDAA Compliant
• Yes
• Certifications
• CE, FCC, IC
• Ambient Operating Temperature
• -30 to 40° C (-22 to 104° F)
• Ambient Operating Humidity
• 5 to 95% noncondensing

• Software

• Application Requirements
• UniFi Network
• Version 9.0.114 and later (U7 Pro XG - White)
• Version 9.1.120 and later (U7 Pro XG - Black)

Garancia fogyasztók részére

• 2 év kötelező jótállás (gyártó által biztosított szervizgarancia)

Garancia nem fogyasztók részére

• 1 év gyártó által biztosított szervizgarancia
