APC UPS 3000VA SMT3000IC SZÜNETMENTES TÁPEGYSÉG C13/C19/C20 SMART VONALI-INTERAKTÍV

• Output

• Max Configurable Power (Watts)
• 2.7kWatts / 3.0kVA
• Output Voltage Note
• Configurable for 220 : 230 or 240 nominal output voltage
• Output Voltage Distortion
• Less than 5 %
• Output Frequency (sync to mains)
• 50/60 Hz +/- 3 Hz Sync to mains
• Other Output Voltages
• 220 V, 240 V
• Topology
• Line interactive
• Waveform type
• Sine wave
• Transfer Time
• 6 ms typical : 10 ms maximum

• Input

• Input frequency
• 50/60 Hz +/- 3 Hz Auto-sensing
• Input voltage range for main operations
• 151 - 302 Adjustable, 160 - 286V
• Number of Power Cords
• 1
• Other Input Voltages
• 220 V, 240 V

• Batteries & Runtime

• Battery type
• Lead-acid battery
• Typical recharge time
• 3hour(s)
• Replacement Battery
• RBC55
• Expected Battery Life (years)
• 3 - 5
• RBC Quantity
• 1
• Battery Charge Power (Watts)
• 271 Watts
• Extendable Run Time
• 1

• Communications & Management

• Interface Port(s)
• SmartSlot, USB
• Control panel
• Multifunction LCD status and control console
• Audible Alarm
• Alarm when on battery : distinctive low battery alarm : configurable delays
• Emergency Power Off (EPO)
• Yes
• Available SmartSlot Interface Quantity
• 1

• Surge Protection and Filtering

• Surge energy rating
• 365Joules
• Filtering
• Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449

• Physical

• Maximum Height
• 435MM, 43.5CM
• Maximum Width
• 197MM, 19.7CM
• Maximum Depth
• 544MM, 54.4CM
• Net Weight
• 52.5KG
• Shipping weight
• 63.7KG
• Shipping Height
• 699MM, 69.9CM
• Shipping Width
• 381MM, 38.1CM
• Shipping Depth
• 762MM, 76.2CM
• Color
• Black
• Units per Pallet
• 9.0

• Environmental

• Operating Temperature
• 0 - 40 °C
• Operating Relative Humidity
• 0 - 95 %
• Operating Elevation
• 0 - 3048meters
• Storage Temperature
• -15 - 45 °C
• Storage Relative Humidity
• 0 - 95 %
• Storage Elevation
• 0 - 15240meters
• Audible noise at 1 meter from surface of unit
• 53.0dBA
• Online thermal dissipation
• 375.0BTU/hr

Garancia fogyasztók részére

• 3 év kötelező jótállás (gyártó által biztosított szervizgarancia)

Garancia nem fogyasztók részére

• 3 év gyártó által biztosított szervizgarancia
