CYBERPOWER UPS OLS1500EA MAINSTREAM ONLINE TORONY SZÜNETMENTES TÁPEGYSÉG, KETTŐS KONVERZIÓ

• General

• Phase
• Single Phase
• Form Factor
• Tower
• UPS Topology
• Online Double Conversion
• Energy Saving Technology
• ECO Mode Efficiency ? 95%
• Active PFC Compatibility
• Yes

• Input

• Generator Compatibility
• Yes
• Nominal Input Voltage ( Vac )
• 230 ? 10%
• Input Voltage Range ( Vac )
• 200 ~ 300
• Adjustable Voltage Range ( Vac )
• 0~30% Load for 80 ~ 300 Vac
  0~50% Load for 120 ~ 300 Vac
  0~75% Load for 160 ~ 300 Vac
  0~100% Load for 200 ~ 300 Vac
• Input Frequency ( Hz )
• 50 ? 10 / 60 ? 10
• Input Frequency Detection
• Auto-sensing
• Rated Input Current ( A )
• 9
• Input Power Factor
• 0.98
• Input Connector Type
• IEC C14
• Detachable Power Cord Plug Type
• Schuko x 1
• Power Cord Length (ft.)
• 5
• Power Cord Length (m.)
• 1.5

• Output

• Capacity (VA)
• 1500
• Capacity (Watts)
• 1350
• On Battery Waveform
• Pure Sine Wave
• On Battery Voltage(s) ( Vac )
• 208 ? 1 % / 220 ? 1 % / 230 ? 1 % / 240 ? 1 %
• Output Voltage Setting
• Configurable
• On Battery Frequency ( Hz )
• 50 ? 0.5% / 60 ? 0.5%
• Output Frequency Setting
• Configurable
• Power Factor
• 0.9
• ECO Mode Voltage Tolerance
• ? 15 %
• Overload Protection
• Internal Current Limiting, Circuit Breaker, Fuse
• Overload Protection (Line Mode)
• 110~120% Load for 1 min, ?120% Load Immediately
• Overload Protection (Battery Mode)
• 110~120% Load for 10 sec, ?120% Load Immediately
• Overload Protection (Bypass Mode)
• ?130% Load Immediately
• Crest Factor
• 3 : 1
• Harmonic Distortion (Linear Load)
• THD?3%
• Harmonic Distortion (Non-linear Load)
• THD?5%
• Internal Bypass
• Automatic Bypass, Manual Bypass
• Outlet(s) - Total
• 4
• Outlet Type
• IEC C13 x 2 / Schuko x 2
• Outlet(s) - Battery & Surge Protected
• 4
• Typical Transfer Time ( ms )
• 0

• Battery

• Runtime at Half Load ( min )
• 11
• Runtime at Full Load ( min )
• 3.6
• Typical Recharge Time ( Hours )
• 4
• Maximum Charging Current ( A )
• 1.5
• Start On Battery
• Yes
• Smart Battery Management (SBM)
• Yes
• User-replaceable
• No
• Battery Type
• Sealed Lead-acid
• Compatible Extended Battery Module (EBM)
• BPSE48V40A
• Max. EBM Quantity ( pcs )
• 3

• Surge Protection & Filtering

• Surge Suppression ( Joules )
• 345
• EMI/RFI Filtration
• Yes

• Management & Communications

• LCD Panel
• Yes
• LCD Types
• Color LCD
• LCD Information Display
• Operation Type, Power Status, Battery Status, Load Status, Fault & Warning, Other Information, Event & Log
• LCD Setting & Control
• Mode Setting, Alarm Setting, Input & Output, Battery Setting
• HID Compliant USB Port(s)
• 1
• Dry Contact (with Relay)
• Yes
• Emergency Power Off (EPO) Port
• Yes
• Audible Alarms
• Battery Mode, Low Battery, Overload, Overcharge, Overheat, UPS Fault, Replace Battery
• Management Cable ( pcs )
• USB Cable x1
• Power Management Software
• PowerPanel Business (Recommended)
• SNMP/HTTP Remote Monitoring
• Yes - with optional RMCARD205

• Physical

• Enclosure Construction
• Metal
• Color
• Black
• Dimensions (WxHxD) (in.)
• 5.9 x 8.9 x 15.5
• Dimensions (WxHxD) (mm.)
• 151 x 225 x 394
• Weight (lbs.)
• 31.7
• Weight (kg.)
• 14.4

• Environmental

• Operating Temperature (°F)
• 32 ~ 104
• Operating Temperature (°C)
• 0 ~ 40
• Operating Relative Humidity (Non-condensing) ( % )
• 20 ~ 90
• Operating Elevation ( feet/meters )
• 0-4,921 feet (0-1,500 meters)
• Storage Temperature (°F)
• -4 ~ 122
• Storage Temperature (°C)
• -20 ~ 50
• Storage Relative Humidity (Non-condensing) ( % )
• 10 ~ 90
• Storage Elevation ( feet/meters )
• 0-4,921 feet (0-1,500 meters)
• Online Thermal Dissipation ( BTU/hr )
• 682
• Variable Speed Fans
• 20 steps automatically
