UBIQUITI ACCESS POINT - NANOBEAM 5AC GEN2

UBIQUITI Access Point - NanoBeam 5AC Gen2

40 990 Ft 32 276 Ft + ÁFA

Hálózat > Access Point

raktáron

  • HA MOST MEGRENDELED
  • Házhoz szállítjuk
    KEDDRE (2024-04-02)
  • Ügyfélszolgálatunkon átveheted már
    KEDDEN (2024-04-02) 9:30 - 17:30
  • mysoft azonosító
    2-2002991
Adatlap frissítve: 2024. 03. 28. 11:01:29



cib
GLS
  • NBE-5AC-Gen2

  • Dimensions (Mount Included)
  • 189 x 189 x 125 mm (7.44 x 7.44 x 4.92")
  • Weight (Mount Included)
  • 530 g (1.17 lb)
  • Gain
  • 19 dBi
  • Networking Interface
  • (2) 10/100/1000 Ethernet Port, Wi-Fi for Management
  • Enclosure
  • Outdoor UV Stabilized Plastic
  • Max. Power Consumption
  • 8.5W
  • Power Supply
  • 24V, 0.5A Gigabit PoE Adapter (Included)
  • Power Method
  • Passive PoE (Pairs 4, 5+; 7, 8 Return)
  • Wind Loading
  • 45.4 N @ 200 km/h (10.2 lbf @ 125 mph)
  • Wind Survivability
  • 200 km/h (125 mph)
  • Certifications
  • CE, FCC, IC
  • Mounting
  • Pole-Mount (Kit Included)
  • Wall-Mount (Not Included)
  • ESD/EMP Protection
  • +/- 24kV Contact/Air
  • Operating Temperature
  • -40 to 80° C (-40 to 176 F)
  • Operating Humidity
  • 5 to 95% Noncondensing
  • Salt Fog Test
  • IEC 68-2-11 (ASTM B117),
  • Equivalent: MIL-STD-810 G Method 509.5
  • Vibration Test
  • IEC 68-2-6
  • Temperature Shock Test
  • IEC 68-2-14
  • Processor Specs
  • Atheros MIPS 74Kc, 720 MHz
  • Memory
  • 128 MB DDR2, 8 MB Flash
  • LEDs
  • Power, Ethernet, (4) Signal Strength
  • Signal Strenght LEDs
  • Software-Adjustable to Correspond to Custom RSSI Levels
  • Max. VSWR
  • 1.5:1
  • Channel Sizes
  • PtP Mode
  • 10/20/30/40/50/60/80 MHz
  • PtMP Mode
  • 10/20/30/40 MHz
  • Polarization
  • Dual Linear
  • RoHS Compliance
  • Yes
  • UV Test
  • IEC 68-2-5 at 40° C (104° F),
  • Equivalent: ETS 300 019-1-4
  • Wind-Driven Rain Test
  • ETS 300 019-1-4,
  • Equivalent: MIL-STD-810 G Method 506.5
  • Operating Frequency MHz

  • Worldwide
  • 5150-5875
  • USA
  • U-NII-1
  • 5150-5250
  • U-NII-2A
  • 5250-5350
  • U-NII-2C
  • 5240-5725
  • U-NII-3
  • 5725-5850
  • Management Radio (MHz)

  • Worldwide
  • 2412 - 2472
  • USA
  • 2412 - 2462
Garancia fogyasztók részére
  • 1 év kötelező jótállás (gyártó által biztosított szervizgarancia)
Garancia nem fogyasztók részére
  • 1 év gyártó által biztosított szervizgarancia
