SAMSUNG QM85R-B 84.5" LFD

• Panel

• Diagonal Size
• 85"
• Type
• Edge LED BLU
• Resolution
• 3840*2160 (4K UHD)
• Pixel Pitch(mm)
• 0.4875 x 0.4875
• Active Display Area(mm)
• 1872.0(H) x 1053.01(V)
• Brightness(Typ.)
• 500 nit
• Contrast Ratio
• 4000:1
• Viewing Angle(H/V)
• 178/178
• Response Time(G-to-G)
• 8ms(Typ.)
• Display Colors
• 16.7M(True Display)1.07B(Ditherd 10bit)
• Color Gamut
• 92% (DCI-P3, CIE 1976)
• Operation Hour
• 24/7
• Haze
• 28%

• Display

• Dynamic C/R
• MEGA
• H-Scanning Frequency
• 30 ~ 81kHZ
• V-Scanning Frequency
• 48 ~ 75HZ
• Maximum Pixel Frequency
• 594MHz

• Sound

• Speaker Type
• Built in Speaker(10W + 10W)

• Connectivity

• Input
• RGB
• DVI-D, Display Port 1.2 (1)
• Video
• HDMI 2.0 (2)
• HDCP
• HDCP2.2
• Audio
• Stereo mini Jack, DVI, HDMI/Audio(Common)
• USB
• USB 2.0 x 2

• Output

• RGB
• HDMI 2.0 (Loop-out)
• Audio
• Stereo mini Jack
• External Control
• RS232C(in/out) thru stereo jack, RJ45
• External Sensor
• IR

• Power

• Type
• Internal
• Power Supply
• AC 100 - 240 V, 50/60 Hz

• Power Consumption

• Max[W/h]
• 308.0
• Typical[W/h]
• 217.0
• Rating[W/h]
• 280.0
• BTU(Max)
• 1050.3
• Sleep mode
• 0.5

• Mechanical Specification

• Dimension (mm)
• Set
• 1897.8 x 1080.8 x 56.7
• Package
• 2090 x 1247 x 260
• Weight (kg)
• Set
• 48.4
• Package
• 63.7
• VESA Mount (mm)
• 600 X 400
• Bezel Width (mm)
• 10.9mm(U/L/R), 12.9mm(B)

• Operation

• Operating Temperature
• 0°C ~ 40°C
• Humidity
• 10.0 % ~ 80.0 %

• Feature

• Key Features
• UHD Signage Display Slim & Light Signage with Built-in MagicInfo S6, SSSP 6.0
• Orientation
• Landscape / Portrait
• Remote Control
• N/A
• Special Features
• H/W : Temperature Sensor,Pivot Display, Clock Battery(168hrs Clock Keeping), Built in Speaker(10W 2ch), Video Wall Daisy Chain(HDCP2.2:4EA,HDCP1.4:7EA), IP5x Rating, Wi-Fi S/W : Auto Source Switching & Recovery, LFD Home UI, Button Lock, Hot key option, Plug&Play (Initial Setting)

• Internal Player

• Processor
• Cortex A72 1.7GHz Quad-Core CPU
• On-Chip Cache Memory
• L1 Instruction Cache : 48KB L1 Data Cache : 32KB L2 Cache : 2MB
• Clock Speed
• 1.7GHz
• Main Memory Interface
• 2.5GB LPDDR4 1.5GHz 64bit
• Graphics
• Graphic resolution : 1920x1080 Output resolution : 3840x2160 (Scale up from graphic processing result.)
• Storage (FDM)
• 8GB (3.88GB Occupied by O/S, 4.12GB Available)
• Multimedia
• Video Decoder : MPEG-1/2/4, H.263, H.264/AVC, UHD H.264/AVC, VC-1, AVS+, HEVC, JPEG, PNG, VP8, VP9 *Audio Decoder : AC3 (DD), MPEG
• IO Ports
• USB 2.0
• Operating System
• Tizen 4.0 (VDLinux)

• Accessory

• Included
• Quick Setup Guide, Warranty Card, Power Cord, Remote Controller, Batteries

Garancia fogyasztók részére

• 3 év kötelező jótállás (gyártó által biztosított szervizgarancia)

Garancia nem fogyasztók részére

• 1 év gyártó által biztosított szervizgarancia
