IP-COM G5312F VEZÉRELHETŐ SWITCH (10X1GBPS; 2X SFP; 1X CONSOLE PORT; L3)

• Hardware specifications

• Standards
• IEEE802.3,IEEE802.3u,IEEE802.3ab,IEEE802.3ad,IEEE802.3z,IEEE802.3x,IEEE802.1p,IEEE802.1q,IEEE802.1w,IEEE802.1d,IEEE802.1s
• LED indicators
• One Link/Act LED indicator for each port
• One Power LED indicator for each device
• One SYS LED indicator for each device
• Interfaces
• 10 x 10/100/1000 Base-T Ethernet ports (Data/Power)
• 2 x 1000 Base-X SFP ports (Data)
• Lightning protection
• Port: 6kV
• Power: 6kV
• Forwarding mode
• Store-and-forward
• Switching capability
• 24Gbps
• Packet forwarding rate
• 17.9Mpps
• Buffer
• 12Mbit
• MAC address table
• 16K
• Input voltage
• 100-240V~ 50/60Hz
• Dimensions
• 294 mm x 179.6 mm x 44 mm(L*W*H)
• Operating environment
• Operating temperature: 0°C - 40?
• Storage temperature: -40°C - 70°C
• Operating humidity: (10% - 90%)RH, non-condensing
• Storage humidity: (5% - 90%)RH, non-condensing

• Software specifications

• Security features
• Supports ARP receiving limit
• Supports unknown MAC address discard
• Supports DoS attack defense
• Supports 802.1x security authentication
• Supports Radius authentication
• VLAN
• Supports IEEE 802.1Q VLAN
• Supports VLAN Layer-3 interfaces
• Supports three port modes: Access, Trunk and Hybrid
• DHCP
• Supports DHCP Server
• Supports DHCP Relay
• Supports DHCP Snooping
• Supports Option 82 policy configuration
• L3 Routing
• Supports VLAN-based routing
• Supports IPv4 static routing
• Supports static ARP
• Port aggregation
• Supports static aggregation
• Supports LACP dynamic aggregation
• Spanning tree
• Supports IEEE 802.1d STP (Spanning Tree Protocol)
• Supports IEEE 802.1w RSTP (Rapid Spanning Tree Protocol)
• Supports IEEE 802.1s MSTP (Multiple Spanning Tree Protocol)
• Supports edge port
• Supports BPDU statistics
• Multicast
• Supports IGMP Snooping V1/V2/V3
• Supports port fast leave
• Port Mirroring
• Supports N: 1 port mirroring
• QoS
• Supports SP (Strict Priority)
• Supports SWRR (Simple Weighted Round Robin)
• Support WRR (Weighted Round Robin)
• Supports 802.1p port trust mode
• Supports DSCP port trust mode
• Supports a maximum of 8 queue service quality mapping
• ACL
• Supports MAC ACL
• Supports IP ACL
• Loading and upgrade
• Supports FTP/TFTP/HTTP upgrade
• Supports configuration import and export
• Cloud management
• Supports configuration delivery from IMS cloud platform
• Supports log reporting and fault detection
• Supports remote maintenance: reboot, backup, upgrade
• Local visualization management
• Supports router, switch, AP, IP camera discovery
• Supports automatic generation of topology
• Supports online/offline status detection for devices
• Supports remotely rebooting the IP camera
• Management and maintenance
• Supports Telnet configuration, Console port configuration
• Supports SNMP V1/V2/V3
• Supports WEB management and maintenance
• Supports Ping/Tracert Detection
