TP-LINK INSIGHT S655I IP KAMERA KÜLTÉRI/BELTÉRI SZÍNES ÉJJELLÁTÓ 5 MEGAPIXEL IR FISHEYE PTZ

• Kamera

• Képérzékelő
• 1/2.7" Progressive Scan CMOS
• Shutter Speed
• 1/3 to 1/10000 s
• Slow Shutter
• Yes
• Min. szükséges megvilágítás
• Color: 0.01 Lux; 0 Lux with IR light
• Day/Night Mechanism
• IR Cut Filter
• Day/Night Switch
• Unified/ Scheduled/ Auto

• LENS

• Type
• Fixed Focal Lens
• Focal Length
• 1.44 mm
• Aperture
• F2.0
• FOV
• Horizontal FOV: 180°, Vertical FOV: 180°, Diagonal FOV:180°
• Lens Mount
• M12*P0.5
• DORI Distance
• Detect: 28.8 m (94 ft)
• Observe:12 m (39 ft)
• Recognize: 5.7 m (19 ft)
• Identify: 2.8 m (9 ft)

• Fisheye Display

• Installation
• Ceiling Mount; Wall Mount; Pendant Mount§
• Display Mode
• Ceiling Mount:
• Fisheye, AR Dewarp, 180 Panorama, 360 Panorama
• Cylinder, 2PTZ, 4PTZ, Fisheye + 8PTZ, Fisheye + 3PTZ, 360 Panorama + 8PTZ, 360 Panorama + 6PTZ, 360 Panorama + PTZ
• Wall Mount:
• Fisheye, 360 Panoramic Unwrap, 360 Panoramic Unwrap+3PTZ, 360 Panoramic Unwrap+8PTZ, 4PTZ, Fisheye + 3PTZ, Fisheye + 8PTZ

• Angle Adjustment (Manual)

• Range
• N/A

• ILLUMINATOR

• IR LED
• Quantity: 4
• Range: 30m
• Wavelength: 850nm
• White LED
• N/A
• Illuminator On/Off Control
• Auto/Scheduled/Always on/Always off

• VIDEO

• Max. Resolution
• 2560 × 1920
• Main Stream
• Frame Rate:
• 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
• 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
• Resolution:
• 2560 × 1920, 2256 × 1696, 2048 × 1536, 1280 × 960
• Note:
• If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps.
• If WDR is on, the frame rate only supports up to 15fps.
• Sub-Stream
• Frame Rate:
• 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
• 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
• Resolution:
• 640 × 480, 320 × 240
• Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps.
• If WDR is on, the frame rate only supports up to 15fps.
• Bit Rate Control
• CBR, VBR
• Video Compression
• Main Stream: H.265+/H.265/H.264+/H.264
• Sub-Stream: H.265/H.264
• H.264 Type
• High Profile
• H.264+
• Main Stream Supported
• H.265 Type
• Main Profile
• H.265+
• Main Stream Supported
• Video Bit Rate
• Main Stream: 256 Kbps to 6 Mbps
• Sub-Stream: 64 Kbps to 512 Kbps

• Image

• Image Settings
• Brightness
• Contrast
• Saturation
• Sharpness
• Exposure
• WDR,
• White Balance
• Prevent Overexposure to Infrared Light
• HLC Adjustable by Client Software
• Image Enhancement
• BLC/3D DNR/HLC/SmartIR
• Wide Dynamic Range
• 120dB
• SNR
• > 52 dB
• Image Parameters Switch
• Yes
• Privacy Mask
• Up to 4 Masks
• ROI
• 1 Region
• OSD Setting
• Yes

• Hang

• Hangkommunikáció
• Two-Way Audio
• Hangbemenet
• Yes
• Hangkimenet
• Yes
• Hangtömörítés
• Yes
• Audio Sampling Rate
• 8KHz
• Environment Noise Filtering
• Yes
• Audio Bit Rate
• 64 Kbps(G.711 alaw)

• Hálózat

• Szabvány
• TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP
• ONVIF
• Yes
• API
• Open Network Video Interface (Profile S/T/G)
• Simultaneous Live View
• 3 Main Streams & 3 Sub-Streams
• Client
• Utility, VIGI App, Web UI, VIGI VMS, VIGI Cloud VMS
• Web Browser
• Google Chrome© 57 and above
• Firefox© 52 and above
• Safari© 11 and above
• Microsoft© Edge 91 and above
• Cloud
• Yes
• Biztonság
• Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication

• Figyelmeztetési és eseménykezelési vezérlés

• Smart Event
• Intrusion Detection
• Line-Crossing Detection
• Region Entering Detection
• Region Exiting Detection
• Abnormal Sound Detection
• Basic Event
• Motion Detection
• Video Tampering Detection
• Exception ( Illegal Login)
• Alarm Linkage
• Memory Card Video Recording
• Message Push
• Audible Warning
• Linkage Method
• N/A
• Output Notification
• Message Push
• Email Alarm
• Upload Capture to FTP

• Fizikai kezelőfelület

• Hálózati csatlakozás
• 1 RJ45 10/100M Self-Adaptive Ethernet Port, PoE
• Alarm
• N/A
• Reset Button
• Yes
• Power
• DC Power Port
• On-board Storage
• Built-In Memory Card Slot, Support MicroSD Card, up to 512 GB§
• Built-in Microphone
• Yes; Records Anything Going on within a 15-ft Radius of the Camera
• Built-in Speaker
• Yes
• Audio
• N/A

• Általános

• Operating Temperature
• -30-60 °C
• Storage Temperature
• -40-60 °C
• Operating Humidity
• 95% or Less (Non-Condensing)
• Storage Humidity
• 95% or Less (Non-Condensing)
• Csomagolás tartalma
• VIGI Network Camera
• Quick Start Guide
• Waterproof Cable Attachments
• Mounting Accessories
• Material
• Metal
• Net Weight
• 0.44 Kg ( without Mounting Accessories)
• 0.48 Kg ( with Mounting Accessories)
• Power Supply
• 12V DC +/- 5%, Max. 11.76 W, 5.5mm Coaxial Power Plug
• PoE: 802.3af/at, class 0, Max. 12.14W
• Protection
• IP67 Weatherproof, IK10 Vandal Proof
• Product Dimensions (L x W x H)
• 5.2 × 5.2 × 2.2 in (132 × 132 × 56mm)
• Certifications
• CE; NTRA; KC; FCC; VCCI; BSMI; ONVIF
