ELO TOUCH 1902L ÉRINTŐKÉPERNYŐS MONITOR ÁLLVÁNNYAL

Kijelző

• Képátló: 19"
  Felbontás: 1280x1024
  Panel: TFT-LCD
  Képarány: 5:4

Csatlakozók

• • 1x VGA
  • 0x DVI
  • 0x DisplayPort
  • 1x HDMI
  • TV-tuner

• Specification

• Touch Technology & Capacity
• PCAP (TouchPro© Projected Capacitive) - 10 Touch
• Diagonal Size
• 19'' diagonal, Active matrix TFT LCD (LED)
• Aspect Ratio
• 5:4
• Active Area
• 14.76" x 11.80" / 374.78 mm x 299.83 mm
• Resolution
• 1280 x 1024
• Other Supported Resolutions
• 640 x 480 @ 60Hz
• 720 x 400 @ 70Hz
• 640 x 400 @ 70Hz
• 800 x 500 @ 60Hz
• 800 x 600 @ 56, 60Hz
• 1024 x 768 @ 60Hz
• 1280 x 720 @ 58Hz, 60Hz
• 1280 x 800 @ 60 Hz
• 1280 x 1024 @ 60Hz
• Viewing Angle
• Horizontal: +/-89° or 178° total / Vertical: +/-89° or 178° total
• Number of Colors
• 16.7 million
• Brightness (typical)
• TouchPro PCAP: 225 nits
• Response Time-total (typical)
• 14 msec
• Contrast Ratio
• 1000:1
• Touch Interface
• USB
• Surface Treatment
• Clear
• On Screen Display
• Accessible through switches along the bottom:
• Controls: Menu, Up, Down, Select
• Settings: Brightness, Contrast, Clock, Phase, H-position, V-position, Auto-Adjust, Sharpness, Color Temperature, OSD Timeout, OSD Language, Volume, Mute, Recall Defaults, Audio Select, Power LED ON/OFF, Touch Thru
• Languages: English, French, Italian, German, Spanish, Japanese, Traditional Chinese, Simplified Chinese, Russian, Korean
• Lockouts: OSD, Power
• I/O Ports
• VGA
• HDMI
• Combo Jack
• DC jack
• USB Type B
• USB 2.0 Type A
• 4x Micro USB
• Speakers
• Two 2W internal speakers
• Input Video Format
• VGA (VGA DE-15 (DB-15) Male connecter cable included)
• HDMI (HDMI cable included)
• Input Video Frequency
• Horizontal: 30 - 82KHz
• Vertical: 50 - 75Hz
• Power Consumption (Typical)
• Monitor + AC/DC adapter
• ON (Default - 80% Brightness): 13.07 W
• ON (Typical - 100% Brightness): 14.58 W
• SLEEP: 0.66 W
• OFF: 0.32 W
• Input Voltage
• 12VDC +/- 5%
• 100-240VAC, 50/60Hz
• Input Connector
• Coaxial power jack (2.1 mm pin outer diameter, 6.4mm barrel inner diameter)
• Peripheral Mounting
• 4x Micro USB side ports (Top, Bottom, Left, Right)
• Monitor Dimensions (without Stand)
• 13.96" x 429.6" x 1.64" / 354.6 mm x 429.6 mm x 41.6 mm
• Monitor Dimensions (with Stand)
• 15.66" x 16.91" x 7.61" / 397.7 mm x 429.6 mm x 193.4 mm
• Shipping Box Dimensions
• With Stand: 18.97" x 20.75" x 10.24" / 482 mm x 527 mm x 260 mm
• Weight (Unpackaged)
• With Stand: 13.9 lbs / 6.3 kg
• Weight (Packaged)
• With Stand: 21.6 lbs / 9.8 kg
• Operating Temperature
• 0°C to 40°C / 32°F to 104°F
• Storage Temperature
• -20°C to 60°C / -4°F to 140°F
• Humidity
• Operating: 20% to 80%; Storage: 10% to 95% (38.7? max wet bulb temperature)
• MTBF
• 50,000 hours demonstrated
• Mounting Options
• VESA 4-hole 100mm mounting interface on rear of unit
• Ingress Protection
• IPX1 - Front only
• Impact Protection
• IK06

• What's in the Box

• Touchmonitor
• Quick Install Guide
• 3x Tie wraps
• VGA cable
• HDMI cable
• Touch USB cable
• Audio cable
• Power brick
• NA Power cable
• EU Power cable
• EEI Label
• 4 x Screws (for E125695)

Garancia fogyasztók részére

• 3 év kötelező jótállás (gyártó által biztosított szervizgarancia)

Garancia nem fogyasztók részére

• 3 év gyártó által biztosított szervizgarancia
