ELO TOUCH 3263L ÉRINTŐKÉPERNYŐS MONITOR

Kijelző

• Képátló: 31.5"
  Felbontás: 1920x1080
  Panel: TFT-LCD
  Képarány: 16:9

Csatlakozók

• • 1x VGA
  • 0x DVI
  • 0x DisplayPort
  • 2x HDMI
  • TV-tuner

• Specification

• Touch Technology & Capacity
• PCAP (TouchPro© Projected Capacitive) - 40 Touch with Palm Rejection and Touch Thru capability
• Touch Thru
• Supports up to 6mm glass/3mm plastic with up to 2 touches. Supports gloves up to 1.4mm
• Touch Interface
• USB
• Diagonal Size
• 31.5'' diagonal, Active matrix TFT LCD (LED)
• On Screen Display
• Accessible through switches on the OSD Control Remote accessory.
• Controls (side): Menu, Up, Down, Select
• Settings: Brightness, Contrast, Clock, Phase, H-position, V-position, Auto-Adjust, Aspect Ratio, Sharpness, Color Temperature, OSD Timeout, OSD Language, Recall Defaults, Video Source, Touch, RTC, MDC, Touch Through
• Languages: English, French, Italian, German, Spanish, Simplified Chinese, Traditional Chinese, Japanese
• Lockouts: OSD, Power
• RTC Settings: The clock/time and the monitor ON/OFF schedule can be changed within this menu. Daylight Saving time is adjusted for automatically and will change the current time by one hour to accommodate daylight savings time.
• See user manual for full details.
• Aspect Ratio
• 16:9
• Active Area (mm)
• 27.5" x 15.47" / 698.4 mm x 392.9 mm
• Resolution
• 1920 x 1080 @ 60hz
• Other Supported Resolutions
• 640x480 @ 60Hz
• 800x600 @ 56/60Hz
• 1024x768 @ 60Hz
• 1280x720 @ 60Hz
• 1280x800 @ 60Hz RB
• 1280x960 @ 60Hz
• 1280x1024 @ 60Hz
• 1366x768 @ 60Hz
• 1366x768 @ 60Hz RB
• 1440x900 @ 60Hz
• 1440x900 @ 60Hz RB
• 1680x1050 @ 60Hz
• 1680x1050 @ 60Hz RB
• 1920x1080 @ 60Hz
• Viewing Angle
• Horizontal: +/-89° or 178° total / Vertical: +/-89° or 178° total
• Number of Colors
• 8-bit (16.7 million)
• Brightness (typical)
• LCD panel: 500 nits
• TouchPro PCAP: 425 nits
• Response Time-total (typical)
• 8 msec
• Contrast Ratio
• 3000:1
• I/O Ports
• HDMI 1.4 x2
• USB 2.0 Type B (for Touch)
• RJ45 (for optional OSD remote)
• VGA
• Video
• 2x HDCP-capable HDMI on Type A connector
• Female DE-15 VGA connector
• Input Video Horizontal Sync frequency range: 31.5 - 80 KHz
• Input Video Vertical Sync (frame rate) frequency range: 47 - 63 KHz
• Power
• Input connector (power): IEC 60320-C14
• Input signal specifications (power): 100-240VAC 50/60Hz
• Maximum Operating Time
• 24 hours/day
• Power Consumption (Typical)
• ON (monitor + AC/DC adapter): 44.3 W
• SLEEP (monitor + AC/DC adapter): 0.61 W
• OFF (monitor + AC/DC adapter): 0.20 W
• Dimensions
• 29.42" x 17.82" x 2.16" / 747.3 mm x 452.7 mm x 55 mm
• Shipping Box Dimensions
• 39.4" x 12.05" x 26.79" / 1000 mm x 306 mm x 680 mm
• Weight (Unpackaged)
• 24.17 lbs / 10.99 Kg
• Weight (Packaged)
• 37.47 lbs / 17.03 Kg
• Operating Temperature
• Portrait/Landscape Mode: 0°C to 40°C / 32°F to 104°F
• Tabletop Mode: 0° C to 35° C / 32°F to 95°F
• Storage Temperature
• Portrait/Landscape Mode: -20°C to 60°C / -4°F to 140°F
• Tabletop Mode: -20° C to 60° C / -4° F to 140° F
• Humidity
• Operating: 20% to 80%
• Storage: 10% to 90% (38.7°C max wet bulb temperature)
• Sealability
• Touchscreen sealed to bezel
• Touchscreen sealed to LCD
• MTBF
• 50,000 hours demonstrated
• Mounting Options
• VESA 400mm x 200mm
• Other Features
• Ambient Light Sensor - changes panel color to match ambient light, Auto Wake
• What's in the Box
• Quick Install Guide
• HDMI 1.4 cable (Type A plug to Type A plug)
• VGA cable (DB-15 male to DB-15 male)
• USB cable (Type A plug to Type B plug)
• RJ45 Wired OSD remote
• Power cable, IEC 60320-C13 to NA plug
• Power cable, IEC 60320-C13 to EU/KR plug
• Power cable, IEC 60320-C13 to UK plug
• Energy label according to EU Regulation 2019/2013
• 8 sets Flushmount Brackets 48 pcs Screws

Garancia fogyasztók részére

• 3 év kötelező jótállás (gyártó által biztosított szervizgarancia)

Garancia nem fogyasztók részére

• 3 év gyártó által biztosított szervizgarancia
