ELO TOUCH 2402L ÉRINTŐKÉPERNYŐS MONITOR ÁLLVÁNY NÉLKÜL

Kijelző

• Képátló: 23,8"
  Felbontás: 1920x1080
  Panel: TFT-LCD
  Képarány: 16:9

Csatlakozók

• • 1x VGA
  • 0x DVI
  • 0x DisplayPort
  • 1x HDMI
  • TV-tuner

• Specification

• Touch Technology & Capacity
• PCAP (TouchPro© Projected Capacitive) - 10 Touch
• Diagonal Size
• 23.8'' diagonal, Active matrix TFT LCD (LED)
• Aspect Ratio
• 16:9
• Active Area
• 20.75" x 11.67" / 527.04 mm x 296.46 mm
• Resolution
• 1920 x 1080 @ 50, 60Hz
• Other Supported Resolutions
• 640 x 480 60Hz
• 640 x 400 70Hz
• 720 x 400 70Hz
• 800 x 500 60Hz
• 800 x 600 56, 60Hz
• 1024 x 768 60Hz
• 1280 x 720 @ 58Hz, 60Hz
• 1280 x 800 60Hz
• 1280 x 1024 60Hz
• 1366 x 768 60Hz, 60Hz RB
• 1440 x 900 60Hz, 60Hz RB
• 1680 x 1050 60Hz, 60Hz RB
• 1920 x 1080 50 60Hz
• Viewing Angle
• Horizontal: +/-89° or 178° total / Vertical: +/-89° or 178° total
• Number of Colors
• 16.7 million
• Brightness (typical)
• TouchPro PCAP: 225 nits
• Response Time-total (typical)
• 16 msec
• Contrast Ratio
• 1000:1
• Touch Interface
• USB
• Surface Treatment
• Clear
• On Screen Display
• Accessible through switches along the bottom:
• Controls: Menu, Up, Down, Select
• Settings: Brightness, Contrast, Clock, Phase, H-position, V-position, Auto-Adjust, Aspect Ratio, Sharpness, Color Temperature, OSD Timeout, OSD Language, Volume, Mute, Recall Defaults, Audio Select, Power LED ON/OFF, Touch Thru
• Languages: English, French, Italian, German, Spanish, Japanese, Traditional Chinese, Simplified Chinese, Russian, Korean
• Lockouts: OSD, Power
• I/O Ports
• VGA
• HDMI
• Combo Jack
• DC jack
• USB Type B
• USB 2.0 Type A
• 4x Micro USB
• Speakers
• Two x 2W internal speakers
• Input Video Format
• VGA (VGA DE-15 (DB-15) Male connecter cable included)
• HDMI (HDMI cable included)
• Input Video Frequency
• Horizontal: 30 - 82KHz
• Vertical: 50 - 75Hz
• Power Consumption (Typical)
• Monitor + AC/DC adapter
• ON (Default - 75% Brightness): 14.33 W
• ON (Typical - 100% Brightness): 16.81 W
• SLEEP: 0.974 W
• OFF: 0.279 W
• Input Voltage
• 12VDC +/- 5%
• 100-240VAC, 50/60Hz
• Input Connector
• Coaxial power jack (2.1 mm pin outer diameter, 6.4mm barrel inner diameter)
• Peripheral Mounting
• 4x Micro USB side ports (Top, Bottom, Left, Right)
• Monitor Dimensions (without Stand)
• 13.94" x 22.62" x 1.69" / 354.1 mm x 574.6 mm x 42.8 mm
• Monitor Dimensions (with Stand)
• 17.04" x 22.62" x 9.17" / 432.9 mm x 574.6 mm x 233 mm
• Shipping Box Dimensions
• Without Stand: 18.11" x 26.77" x 6.65" / 460 mm x 680 mm x 169 mm
• Weight (Unpackaged)
• Without Stand: 14.73 lbs / 6.69 kg
• Weight (Packaged)
• Without Stand: 22.39 lbs / 10.17 kg
• Operating Temperature
• 0°C to 40°C / 32°F to 104°F
• Storage Temperature
• -20°C to 60°C / -4°F to 140°F
• Humidity
• Operating: 20% to 80%; Storage: 10% to 95% (38.7? max wet bulb temperature)
• Sealability
• Touchscreen sealed to bezel; Touchscreen sealed to LCD
• MTBF
• 50,000 hours demonstrated
• Mounting Options
• VESA 4-hole 100mm mounting interface on rear of unit
• Ingress Protection
• IPX1 - Front only
• Impact Protection
• IK06

• What's in the Box

• Touchmonitor
• Quick Install Guide
• 3x Tie wraps
• VGA cable
• HDMI cable
• Touch USB cable
• Audio cable
• Power brick
• NA Power cable
• EU Power cable
• EEI Label
• 4 screws (for E126288)
• 2 x cable cover screws

Garancia fogyasztók részére

• 2 év kötelező jótállás + 1 év gyártó által biztosított szervizgarancia

Garancia nem fogyasztók részére

• 3 év gyártó által biztosított szervizgarancia
