DAHUA CS4226-24ET-240 MENDZSELHETŐ POE SWITCH (CLOUD MENEDZSMENT; 24X 100MBPS AT/AF POE; 2X 1GBPS; 2X 1GBPS SFP; 240W)

• Hardware

• Included Power Adapter
• Yes
• PoE
• Yes
• Ethernet Port
• 24
• Ethernet Port Speed
• 10/100 Mbps
• Optical Port Speed
• 1000 Mbps
• Ethernet Port Uplink Speed
• 10/100/1000 Mbps
• Optical Port Uplink Speed
• 1 Gbps
• Description of Function Slots
• Port 1-24: 24 × RJ-45 10/100 Mbps (PoE); Port 25-26: 2 × RJ-45 10/100/1000 Mbps (combo); Port 25-26: 2 × SFP 1000 Mbps (combo)
• Reset Button
• 1
• Power Supply
• Built-in power supply: 100-240 VDC, 47-63 Hz, max 4 A
• Operating Temperature
• -10 °C to +55 °C (+14 °F to +131 °F)
• Operating Humidity
• 5%-95% (RH), non-condensing
• Storage Temperature
• -40 °C to +70 °C (-40 °F to +158 °F)
• Storage Humidity
• 5%-95% (RH), non-condensing
• Power Consumption
• Idling: ?8.5 W ; Full load: 265 W

• Performance

• Layer
• Layer 2
• Management Type
• Yes
• Smart Managed Switch
• Yes
• MTBF
• 64.20 years
• Switching Capacity
• 8.8 Gbps
• Packet Forwarding Rate
• 6.55 Mpps
• Packet Buffer Size
• 4 Mbit
• Jumbo Frame
• 15K Byte
• MAC Table Size
• 8K
• VLAN Number
• 32
• Communication Standard
• IEEE802.3; IEEE802.3u; IEEE802.3x; IEEE802.3ab; IEEE802.3z

• Feature

• PoE Protocol
• IEEE802.3af; IEEE802.3at; Hi-PoE; IEEE802.3bt
• PoE Power
• Port 1-2 ? 90 W, Port 3-24 ? 30 W, total ? 240 W
• PoE Power Consumption Management
• Yes
• PoE Pin Assignment
• 1,2,4,5(V+),3,6,7,8(V-)
• Long Distance PoE Transmission
• Yes
• VLAN Function
• Port-based VLAN
• IEEE 802.3x Flow Control
• Yes
• DHCP Function
• DHCP Client
• Equipment Management
• Web management; App management

• General

• Statics Protection
• Air discharge: 8 kV; Contact discharge: 6 kV
• Lighting Protection
• Common mode: 4 kV; Differential mode: 2 kV
• Net Weight
• 2.47 kg (5.43 lb)
• Gross Weight
• 3.12 kg (6.86 lb)
• Product Dimensions
• 440 mm × 220 mm × 44 mm (17.32" × 8.66" × 1.73") (L × W × H)
• Packaging Dimensions
• 540 mm × 342 mm × 90 mm (21.26" × 13.46" × 3.54") (L × W × H)
• Casing Material
• Sheet metal
• Installation
• Desktop mount; rack mount
