UBIQUITI AF60-LR AIRFIBER LR 60GHZ PTP RÁDIÓ 38DBI ANTENNÁVAL

UBIQUITI AF60-LR airFiber LR 60GHz PTP rádió 38dBi antennával

182 000 Ft 143 307 Ft + ÁFA

Hálózat > Antenna

raktáron

  • HA MOST MEGRENDELED
  • Házhoz szállítjuk
    SZERDÁRA (2024-04-03)
  • Ügyfélszolgálatunkon átveheted már
    SZERDÁN (2024-04-03) 9:30 - 17:30
  • mysoft azonosító
    10-2113101
Adatlap frissítve: 2024. 03. 29. 14:36:24



cib
GLS
  • Mechanical

  • Dimensions
  • O413 x 360 mm (O16.3 x 14.2")
  • Weight
  • Without mount: 1.5 kg (3.3 lb)
  • With mount: 2.7 kg (6 lb)
  • Enclosure materials
  • Aluminum, UV stabilized polycarbonate
  • Mount material
  • Galvanized steel
  • Mounting
  • Precision Alignment Kit (included)
  • Pole compatibility: O25.4-76.2 mm (O1-3")
  • Wind loading
  • 420 N at 200 km/h (94.4 lbf at 125 mph)
  • Hardware

  • Processor
  • Quad-Core ARM© Cortex© A7
  • Memory
  • 256 MB DDR3
  • Networking interface
  • GbE RJ45 port
  • RF Connections
  • Internal
  • Max. Power Consumption
  • 18W
  • Power method
  • Passive PoE 4-pairs (1, 2+; 3, 6-) (4, 5+; 7, 8-) or 2-pairs (4, 5+; 7, 8- )
  • Power supply
  • 48VDC, 0.65A gigabit PoE adapter (included)
  • Supported Voltage Range
  • 48VDC +/- 10%
  • ESD/EMP Protection
  • Air/Contact: +/- 24kV
  • Operating Temperature
  • -40 to 60° C (-40 to 140° F)
  • Operating Humidity
  • 5 to 95% Noncondensing
  • Certifications
  • FCC, IC, CE
  • LEDs

  • Power
  • Flashing white: bootup in progress
  • White: not connected to UISP console
  • Blue: connected to UISP console
  • Ethernet
  • Flashing blue: ethernet activity
  • GPS
  • Blue: receiving at least (4) GPS satellite signals
  • 60G
  • Blue: active connection
  • Software

  • OS
  • airOS
  • Operating mode
  • PtP only
  • Ubiquiti specific features
  • Integrated 60 GHz radio, discovery protocol, Wave technology
  • Network
  • Bridge mode
  • Services
  • UISP, ping watchdog, NTP client, device discovery
  • Tools
  • Antenna alignment, discovery utility, ping, trace route, speed test
  • Software management
  • Bluetooth management for easy setup over UISP app
  • WEB UI
  • Minimum software requirements
  • Any modern WEB browser/iOS or Android based smartphone
  • System

  • Maximum throughput
  • 1.95 Gbps
  • Maximum range
  • 12+ km
  • Encryption
  • WPA2-PSK (AES)
  • RF

  • Operating Frequency
  • 57 to 71 Ghz
  • GPS
  • Yes
  • Channel Bandwidth
  • 2160, 1080 MHz
Garancia fogyasztók részére
  • 2 év kötelező jótállás (gyártó által biztosított szervizgarancia)
Garancia nem fogyasztók részére
  • 1 év gyártó által biztosított szervizgarancia


mysoft.hu
Ügyfélszolgálat nyitvatartása: H-P: 9:30 - 17:30 | SZ-V: ZÁRVA
Tel.: 06 (1) 424-99-44
Cím: 1131 Budapest, Reitter Ferenc u. 177.
Web: www.mysoft.hu
E-mail:

UBIQUITI AF60-LR airFiber LR 60GHz PTP rádió 38dBi antennával (AF60-LR)
Bruttó ár: 182 000 Ft
Nettó ár: 143 307 Ft
Leírás:
  • Mechanical

  • Dimensions
  • O413 x 360 mm (O16.3 x 14.2")
  • Weight
  • Without mount: 1.5 kg (3.3 lb)
  • With mount: 2.7 kg (6 lb)
  • Enclosure materials
  • Aluminum, UV stabilized polycarbonate
  • Mount material
  • Galvanized steel
  • Mounting
  • Precision Alignment Kit (included)
  • Pole compatibility: O25.4-76.2 mm (O1-3")
  • Wind loading
  • 420 N at 200 km/h (94.4 lbf at 125 mph)
  • Hardware

  • Processor
  • Quad-Core ARM© Cortex© A7
  • Memory
  • 256 MB DDR3
  • Networking interface
  • GbE RJ45 port
  • RF Connections
  • Internal
  • Max. Power Consumption
  • 18W
  • Power method
  • Passive PoE 4-pairs (1, 2+; 3, 6-) (4, 5+; 7, 8-) or 2-pairs (4, 5+; 7, 8- )
  • Power supply
  • 48VDC, 0.65A gigabit PoE adapter (included)
  • Supported Voltage Range
  • 48VDC +/- 10%
  • ESD/EMP Protection
  • Air/Contact: +/- 24kV
  • Operating Temperature
  • -40 to 60° C (-40 to 140° F)
  • Operating Humidity
  • 5 to 95% Noncondensing
  • Certifications
  • FCC, IC, CE
  • LEDs

  • Power
  • Flashing white: bootup in progress
  • White: not connected to UISP console
  • Blue: connected to UISP console
  • Ethernet
  • Flashing blue: ethernet activity
  • GPS
  • Blue: receiving at least (4) GPS satellite signals
  • 60G
  • Blue: active connection
  • Software

  • OS
  • airOS
  • Operating mode
  • PtP only
  • Ubiquiti specific features
  • Integrated 60 GHz radio, discovery protocol, Wave technology
  • Network
  • Bridge mode
  • Services
  • UISP, ping watchdog, NTP client, device discovery
  • Tools
  • Antenna alignment, discovery utility, ping, trace route, speed test
  • Software management
  • Bluetooth management for easy setup over UISP app
  • WEB UI
  • Minimum software requirements
  • Any modern WEB browser/iOS or Android based smartphone
  • System

  • Maximum throughput
  • 1.95 Gbps
  • Maximum range
  • 12+ km
  • Encryption
  • WPA2-PSK (AES)
  • RF

  • Operating Frequency
  • 57 to 71 Ghz
  • GPS
  • Yes
  • Channel Bandwidth
  • 2160, 1080 MHz

Garancia fogyasztók részére: 2 év kötelező jótállás (gyártó által biztosított szervizgarancia)
Garancia nem fogyasztók részére: 1 év gyártó által biztosított szervizgarancia
Adatlap frissítve: 2024. 03. 29. 14:36:24
mysoft azonosító: 10-2113101
Az adatok tájékoztató jellegűek!
