STAR TSP143IV UE USB-C MONO BLOKKNYOMTATÓ

Funkciók

• • Másolás
  • Szkennelés
  • FAX
  • Duplex nyomtatás

Csatlakozók

• • USB
  • LAN
  • Wi-Fi
  • Párhuzamos port

Nyomtatási méret

Tálcák

• 1. tálca:
  2. tálca:

• Specification

• Printer Method
• Direct Line Thermal
• Print Speed
• 250 mm/sec
• Printer Case Color
• White or Gray
• Connectivity
• TSP143IV UE Models: USB/LAN Dual Interface (USB-C and USB-A), Android Open Accessory (AOA), CloudPRNT Next (with updated firmware)
• Print Resolution
• 203 dpi (8 dots per mm)
• No. of Columns
• Star Mode = 48
• Font Size
• 12 x 24
• Character Set
• ANK 95, 32 Int 128 Graphic plus Chinese, Japanese, Korean, Taiwanese
• International Code Pages
• Star Mode=48
• Bar Codes
• Extended barcode functionality - 9 versions / PDF 417, Maxicode Option
• Line Spacing
• 3 mm or 4 mm or programmable
• Paper Width
• 80mm standard, 58mm with paper guide
• Paper Thickness
• 0.049 ~ 0.085 mm
• Paper Roll Diameter
• Up to 83 mm
• Paper Loading
• "Drop-In & Print"
• Paper-Out Sensor
• Yes
• Maximum Print Width
• 80mm paper = 72mm, 58mm paper = 50.8mm
• Top Margin
• 11 mm default
• Auto-Cutter
• Guillotine (Partial Cut Only)
• Cover-Open Sensor
• Yes
• Logo Store Capacity
• 512KB Internal Printer Memory
• Journal Capability
• Available through Starmicronicscloud.com
• Drivers Available
• Windows 10, Windows 8.1, Windows© XP 32 Bit, Vista 32/64 Bit, Windows 7 32/64 Bit, Server 2008 32/64 Bit, XP Embedded, POSReady2009, OPOS™, JavaPOS™ (Windows/Mac/Linux), USB Vendor Clss, CUPS (Mac/Linux), Mac, Mac OS X, Linux™, StarPRNT SDK (iOS/Android/Windows Desktop/UWP), StarXpand SDK (React Native), Star WebPRNT Brower (Android), Star PassPRNT (iOS/Android/UWP)
• Digitally Signed (WHQL)
• Yes
• Emulation Modes
• Star Graphics Mode/StarPRNT
• Peripheral Drive Circuit
• 2 circuits, (24V max. 1A), 1 compulsion input
• Power Consumption
• Average 1.6 Amp. Printing, 0.1 Amp. Standby [Approx. 43W while printing; up to 53 W with a 1.5 A device connected. Approx 3.5 W in Standby;up to 13 W with a 1.5A device connected]
• Operating Temperature
• 5oC to 45oC
• Operating Humidity
• 10% - 90% RH (without condensation)
• Storage Temperature
• Temperature: -20oC to 60oC
• Storage Humidity
• 10% - 90% RH
• Dimensions
• 140 X 123 X 169 (w x h x d)mm
• Weight
• 1.3kg
• Safety and Regulatory Standards
• UL, C-UL, TuV, FCC, VCCI, EN55022, CE
• Reliability MCBF
• 60 Million Lines
• Print Head
• 100km
• Auto-Cutter Reliability
• 2 Million Cuts
• Sustainability*
• Eco Friendly Packaging

• What's in the Box

• Power Cable
• LAN Cable (UE model only)
• USB Cable
• Paper Guide
• Rubber Feet
• Safety Instructions
• Easy Setup Guide

Garancia fogyasztók részére

• 2 év kötelező jótállás (gyártó által biztosított szervizgarancia)

Garancia nem fogyasztók részére

• 1 év gyártó által biztosított szervizgarancia
