HILOOK VI-K23P HYBRID KAPUTELEFON SZETT

• Door station/Video parameters

• Resolution
• 1920 x 1080
• FOV
• Horizontal: 66.2°,Vertical: 37.2°

• Door station/Audio parameters

• Audio input
• Built-in omnidirectional microphone
• Audio output
• Built-in loudspeaker

• Door station/Device interfaces

• I/O output
• 1 relay output
• Four-wire
• 1 for 4-wire interface

• Door station/General

• Power supply
• 12 VDC
• Power consumption
• Max. 5 W
• Working temperature
• -10° C to 55° C (14° F to 131° F)
• Working humidity
• 10% to 90%
• Dimensions
• 135.14 mm × 49.6 mm × 41.93 mm (5.32" × 1.95" × 1.65")

• Indoor station/System parameters

• Operation system
• Embedded Linux operation system
• RAM
• 128 MB
• ROM
• 32 MB

• Indoor station/Display parameters

• Size
• 7-inch colorful TFT screen
• Operation method
• Capacitive touch screen
• Type
• Colorful TFT screen
• Resolution
• 1024 × 600

• Indoor station/Video parameter

• Resolution
• /
• Lens
• /
• WDR
• /
• FOV
• /

• Indoor station/Audio parameters

• Audio input
• Built-in omnidirectional microphone
• Audio output
• Built-in loudspeaker
• Audio compression Rate
• 64 Kps
• Audio compression standard
• G.711 U G.711 A
• Volume adjustment
• Adjustable
• Audio quality
• Noise suppression and echo cancellation

• Indoor station/Capacity parameters

• Linked IPC capacity
• 16
• Notice capacity
• 200
• Linked indoor extensions capacity
• 5
• Linked doorphone capacity
• 2 analog doorphones, 15 IP doorphones Max.

• Indoor station/Network parameters

• Wi-Fi
• Wi-Fi 802.11 b/g/n
• 3G/4G
• /
• Bluetooth
• /
• Protocol
• TCP/IP, SIP, RTSP

• Indoor station/Device interfaces

• Network interface
• 1 RJ-45 10/100 Mbps self-adaptive
• RS-485
• 1
• Alarm input
• 2-ch alarm inputs
• Alarm output
• 2
• Power input
• 1, 12 VDC
• TAMPER
• /
• TF card
• Max to 128 G, SD 2.0 or lower version
• USB interface
• /
• Four-wire interface
• 2

• Indoor station/General

• Button
• 0
• Power supply
• IEEE802.3af, Standard PoE,12V DC
• Power consumption
• < 6 W
• Working temperature
• -10 °C to 50 °C (14 °F to 122 °F)
• Working humidity
• 10% to 90%
• Dimensions (W × H × D)
• 200 mm × 140 mm × 23.6 mm (7.9" × 5.5" × 0.9")
• Installation
• Surface mounting
• Application environment
• Indoor
• Protective level
• /
• Weight
• With package: 365 g
• Without package: 355 g

Garancia fogyasztók részére

• 2 év kötelező jótállás (gyártó által biztosított szervizgarancia)

Garancia nem fogyasztók részére

• 2 év gyártó által biztosított szervizgarancia
