UBIQUITI UA-G3-B UNIFI ACCESS READER G3 NFC OLVASÓ (FEKETE)

• Overview

• Dimensions
• 93 x 40 x 36.5 mm (3.7 x 1.6 x 1.4")
• NFC Card & Keyfob Access
• Yes
• Apple/Google Wallet
• Yes
• Mobile Unlock
• Yes
• Handwave Request to Exit
• Yes
• NDAA Compliant
• Yes
• UL 294 Level
• Destructive attack: Level I
• Line security: Level I
• Endurance: Level I
• Standby power: Level I
• Weatherproofing
• IP55

• Mechanical

• Weight
• 82 g (2.9 oz)
• Enclosure Material
• Polycarbonate, glass
• Mount Material
• Aluminum alloy
• Mounting
• In-wall, gang box (Included)
• Junction box (Optional)

• Hardware

• Indoor and Outdoor Use
• Yes
• Ambient Operating Temperature
• -30 to 45° C
• (-22 to 113° F)
• Ambient Operating Humidity
• 5 to 90% noncondensing
• Networking Interface
• (1) 10/100 MbE RJ45 port
• Connectivity
• BLE 4.1
• NFC
• Power Method
• PoE
• UL 294 Power-limited Class 2 PSU
• UL 60950-1/62368-1 LPS/PS2 PSU
• Max. Power Consumption
• 5W
• Supported Voltage Range
• 48V DC
• ESD/EMP Protection
• Air: +/-15kV, contact: +/-8kV
• Sensors
• Proximity sensor
• Speaker
• Yes
• LEDs
• R/G/B/W
• Button
• (1) Factory-reset
• NFC Frequency
• 13.56 MHz
• NFC Read Range
• < 30 mm (1.18'')
• NFC Technology
• ISO/IEC 14443A / 14443B / 15693 / 18092 (Ecma 340)
• MIFARE Classic / MIFARE DESFIRE
• Sony FeliCa™ (ID only)
• NFC Forum tags T1T, T2T, T3T, T4T and T5T
• ECP 2.0
• PoE Cabling Requirements
• Cat 5e cabling is the minimum performance category recommended. The performance category utilized should match the transmission speed required at the installation site.
• The minimal conductor gauge permitted to connect between the PSE or power injector and the PD shall be 26 AWG (0.13 mm2 ) for patch cords; 24 AWG (0.21 mm2 ) for horizontal or riser cable.
• UL 294 Statement
• Compliance with IEEE 802.3 specifications was not verified as part of UL 294.
• The equipment is intended to comply with the section of the National Electrical Code, ANSI/NFPA 70, Article 725.121, Power Sources for Class 2 and Class 3 Circuits.
• CAN/ULC-60839-11-1 Grade
• Grade assignment: I
• Certifications
• CE, FCC, IC, UL 294, CAN/ULC-60839-11-1
• Document number, and issue date and/or revision level
• UA-G3, V01

• Software

• Management Application
• Access
• Software Information
• The software version can be checked at https://unifi.ui.com

Garancia fogyasztók részére

• 2 év kötelező jótállás (gyártó által biztosított szervizgarancia)

Garancia nem fogyasztók részére

• 1 év gyártó által biztosított szervizgarancia
