APC SMART SRT 1000VA XLI 230V SZÜNETMENTES TÁPEGYSÉG

• Main

• Run time for load 1000 W
• Min-max: 100-1000 W
• 8min 27s
• Max. Capacity Used
• 100 %
• Main Input Voltage
• 230 V
• Other Input Voltage
• 220 V
• 240 V
• Main Output Voltage
• 230 V
• Other Output Voltage
• 220 V
• 240 V
• rated power in W
• 1000 W
• rated power in VA
• 1000 VA
• Input Connection Type
• IEC 60320 C14
• nb of power socket outlets
• 6 IEC 60320 C13
• cable length
• 1.83 m
• number of cables
• 1
• battery type
• Lead-acid battery
• provided equipment
• CD with software
• Communication cable
• Documentation CD
• Installation guide
• Removable support feet
• USB cable
• Warranty card

• General

• product web sub-family
• High density
• Number of power module free slots
• 0
• Number of power module filled slots
• 0
• redundant
• No

• Physical

• colour
• Black
• height
• 43.2 cm
• width
• 8.5 cm
• depth
• 50.5 cm
• net weight
• 20.5 kg
• mounting preference
• No preference
• mounting mode
• Rack-mounted with kit
• two post mountable
• 0
• USB compatible
• Yes
• mounting position
• Vertical

• Input

• network frequency
• 40...70 Hz auto-sensing
• input voltage limits
• 100...275 V 40% load
• 176...275 V

• Output

• Maximum configurable power in W
• 1000 W
• harmonic distortion
• Less than 2 %
• output frequency
• 50/60 Hz +/- 3 Hz sync to mains
• crest factor
• 3 : 1
• UPS type
• Double conversion online
• Wave type
• Sine wave
• bypass type
• Built-in bypass
• Maximum configurable power in VA
• 1000 VA

• Environmental

• ambient air temperature for operation
• 0.40 °C
• relative humidity
• 0.95 % non-condensing
• operating altitude
• 0...10000 ft
• ambient air temperature for storage
• -20.50 °C
• storage Relative Humidity
• 0.95 % Non-condensing
• storage altitude
• 0.00.15240.00 m
• acoustic level
• 50 dBA
• heat dissipation
• 317 Btu/h
• IP degree of protection
• IP20

• Batteries & Runtime

• number of battery filled slots
• 1
• number of battery free slots
• 0
• Battery recharge time
• 3 h
• number of battery replacement quantity
• 1
• battery voltage
• 48 V
• battery charger power
• 97 W rated
• Battery power in VAH
• 293 VAh runtime
• battery life
• 3.5 year(s)
• battery option
• SRT48BP 1 879 VAh
• SRT48BP 2 1465 VAh
• SRT48BP 3 2051 VAh
• SRT48BP 4 2637 VAh
• SRT48BP 5 3223 VAh
• SRT48BP 6 3809 VAh
• SRT48BP 8 4981 VAh
• SRT48BP 10 6153 VAh
• extended runtime
• 1

• Communications & Management

• free slots
• 1
• control panel
• Multifunction LCD status and control console
• alarm
• Audible and visible alarms prioritized by severity
• Emergency power off
• Yes

• Surge Protection and Filtering

• Surge energy rate
• 432 J

Garancia fogyasztók részére

• 3 év kötelező jótállás (gyártó által biztosított szervizgarancia)

Garancia nem fogyasztók részére

• 2 év gyártó által biztosított szervizgarancia
