APC SMT750RMI2UNC SMART-UPS 750VA RM 2U RACK LCD SZÜNETMENTES TÁPEGYSÉG HÁLÓZATI KÁRTYÁVAL

• Main

• Run time for load 500 W
• Min-max: 50-500 W
• 5min 27s
• Max. Capacity Used
• 100 %
• Main Input Voltage
• 230 V
• Other Input Voltage
• 220 V
• 240 V
• Main Output Voltage
• 230 V
• Other Output Voltage
• 220 V
• 240 V
• rated power in W
• 500 W
• rated power in VA
• 750 VA
• Input Connection Type
• IEC 320 C14
• nb of power socket outlets
• 4 IEC 320 C13
• 2 IEC Jumpers
• number of rack unit
• 2U
• battery type
• Lead-acid battery
• provided equipment
• CD with software
• Documentation CD
• Installation guide
• Rack mounting support rails
• Smart UPS signalling RS-232 cable
• Temperature probe
• USB cable

• General

• Number of power module filled slots
• 0
• Number of power module free slots
• 0
• redundant
• No

• Physical

• colour
• Black
• height
• 8.9 cm
• width
• 43.2 cm
• depth
• 40.6 cm
• net weight
• 17.24 kg
• mounting location
• Front
• mounting preference
• Lower
• mounting mode
• Rack-mounted
• two post mountable
• 1
• USB compatible
• Yes

• Input

• input voltage limits
• 151...302 V adjustable
• 160...286 V
• network frequency
• 50/60 Hz +/- 3 Hz auto-sensing

• Output

• harmonic distortion
• Less than 5 %
• Maximum configurable power in VA
• 750 VA
• Maximum configurable power in W
• 500 W
• Transfer time
• 2 ms typical
• UPS type
• Line interactive
• Wave type
• Sine wave
• output frequency
• 50/60 Hz +/- 3 Hz sync to mains

• Environmental

• acoustic level
• 42 dBA
• heat dissipation
• 46 Btu/h
• operating altitude
• 0...10000 ft
• ambient air temperature for operation
• 0.40 °C
• ambient air temperature for storage
• -15.45 °C
• storage altitude
• 0.00.15240.00 m
• relative humidity
• 0.95 %
• storage Relative Humidity
• 0.95 %

• Batteries & Runtime

• extended runtime
• 0
• number of battery filled slots
• 0
• number of battery free slots
• 0
• Battery recharge time
• 3 h
• number of battery replacement quantity
• 1
• battery life
• 3.5 year(s)
• Battery power in VAH
• 168 VAh runtime
• battery charger power
• 56 W rated

• Communications & Management

• alarm
• Alarm when on battery : distinctive low battery alarm : configurable delays
• control panel
• LED status display with on line : on battery : replace battery and overload indicators
• Multifunction LCD status and control console
• Emergency power off
• Optional
• preinstalled device
• Network management card 2 with environmental monitoring

• Surge Protection and Filtering

• Surge energy rate
• 459 J

Garancia fogyasztók részére

• 3 év kötelező jótállás (gyártó által biztosított szervizgarancia)

Garancia nem fogyasztók részére

• 3 év gyártó által biztosított szervizgarancia
