DAHUA SD3D216NB-GNY IP PT DÓMKAMERA (2MP, 5-80MM, KÜLTÉRI, IR80M; H265+, IP66, POE+; 12VDC)

• Camera

• Image Sensor
• 1/2.8" CMOS
• Pixel
• 2 MP
• Max. Resolution
• 1920 (H) × 1080 (V)
• ROM
• 128 MB
• RAM
• 128 MB
• Electronic Shutter Speed
• 1 s-1/30,000 s
• Scanning System
• Progressive
• Min. Illumination
• 0.005 lux@F1.6 (Color, 30 IRE);
• 0.0005 lux@F1.6 (B/W, 30 IRE);
• 0 lux (Illuminator on)
• Illumination Distance
• 80 m (262.47 ft) (IR)
• Illuminator On/Off Control
• Zoom Prio; Manual; Auto; Off
• Illuminator Number
• 3 (IR)

• Lens

• Focal Length
• 5.0 mm-80 mm
• Max. Aperture
• F1.6-F3.5
• Field of View
• H: 54.4°-4.1° ; V: 31.4°-2.3°; D: 61.3°-4.7°
• Optical Zoom
• 16×
• Focus Control
• Auto; Semi-auto; Manual
• Close Focus Distance
• 0.1 m-1 m (0.33 ft-3.28 ft)
• Iris Control
• Fixed
• DORI Distance
• Lens: 5.0 mm-80 mm
• Detect: 1,103.4 m
• Observe: 435.9 m
• Recognize: 220.7 m
• Identify: 110.3 m

• PTZ

• Pan/Tilt Range
• Pan: 0° to 360° endless; Tilt: -15° to +90°, auto flip 180°
• Manual Control Speed
• Pan: 0.1°-40°/s; Tilt: 0.1°-40°/s
• Preset Speed
• Pan: 0.1°-40°/s; Tilt: 0.1°-40°/s
• Preset
• 300
• Power-off Memory
• Yes
• Idle Motion
• Preset
• PTZ Protocol
• DH-SD

• Smart Event

• IVS
• Tripwire; intrusion

• Intelligence

• SMD
• SMD 3.0

• Video

• Video Compression
• Smart H.265+;H.265;Smart H.264+;H.264B;H.264M;H.264H;MJPEG(Sub Stream 1)
• Streaming Capability
• 2 streams
• Resolution
• 1080p (1920 × 1080); 1.3MP (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
• Video Frame Rate
• Main stream: 1080p/1.3M/720p @(1-25/30 fps)
• Sub stream: D1/VGA/CIF@ (1-25/30 fps)
• Bit Rate Control
• CBR/VBR
• Video Bit Rate
• H.264: 64 kbps-8,192 kbps
• H.265: 25 kbps-6,400 kbps
• Day/Night
• Auto (ICR); Color/B/W
• BLC
• Yes
• WDR
• 120 dB
• HLC
• Yes
• White Balance
• Auto; indoor; outdoor; ATW; manual; sodium lamp; natural light; street lamp
• Gain Control
• Auto; manual
• Noise Reduction
• 2D NR; 3D NR
• Motion Detection
• Yes
• Region of Interest (RoI)
• Yes
• Defog
• Electronic Image Stabilization (EIS)
• Digital Zoom
• 5×
• Image Rotation
• 180°
• S/N Ratio
• >55 dB

• Network

• Network Port
• RJ-45 (10/100 Base-T)
• Network Protocol
• HTTP;HTTPS;TCP/IP;IPv4;RTSP;UDP;SMTP;NTP;DHCP;DNS;DDNS;IPv6;SSL;FTP;ARP;RTCP;RTP;IP Filter;RTMP
• Interoperability
• CGI;SDK;ONVIF (Profile S & Profile T)
• Streaming Method
• Unicast/Multicast
• User/Host
• 20 (total bandwidth: 64 M)
• Storage
• Micro SD card (256 GB); FTP
• Browser
• IE 7 and later versions;
• All Chrome versions;
• All Firefox versions;
• All Safari versions
• Management Software
• DSS Pro
• Mobile Client
• iOS;Android

• Certification

• Certifications
• CE: EN55032/EN55024/EN50130-4

• Port

• Alarm Linkage
• Capture; recording; send email
• Alarm Event
• Motion/tampering detection; network disconnection detection; IP conflict detection; memory card state detection; memory space detection

• Power

• Power Supply
• 12 VDC, 2 A +/- 10%
• PoE+ (802.3at)
• Power Consumption
• Basic: 8 W
• Max. (Basic power consumption + WDR + intelligence on + IR on + PTZ operation + Heater ): 18 W (12 VDC)

• Environment

• Operating Temperature

• -30 °C to +60 °C (-22 °F to +140 °F)
• Operating Humidity
• <95%
• Protection
• IP66;TVS 6000 V lightning proof; surge protection; voltage transient protection

• Structure

• Product Dimensions
• 240 mm × 151.5 mm (9.45" × 5.94")
• Net Weight
• 1.5 kg (3.31 lb)
• Gross Weight
• 2.5 kg (5.51 lb)

• Filter

• Remarks
• The precision of the presets for PTZ cameras might vary depending on different series. For scenes with high requirements on the precision, contact your local sales representative for assistance with selecting the model.
