ASUS ALAPLAP ROG STRIX B550-F GAMING (AM4, ATX)

• CPU

• AMD Ryzen 5000 Series/ 5000 G-Series/ 4000 G-Series/ 3000 Series Desktop Processors

• Memory

• 3rd Gen AMD Ryzen Processors
• 4 x DIMM, Max. 128GB, 4400(O.C)/4266(O.C)/4133(O.C)/4000(O.C)/3866(O.C)/3600(O.C)/3466(O.C.)/3200/3000/2800/2666/2400/2133 MHz, Un-buffered Memory*
• Dual channel memory architecture
• OptiMem II
• *ECC memory(ECC mode) support varies by CPU.

• Graphics

• 1 x DisplayPort 1.2
• 1 x HDMITM 2.1 (4K@60HZ)

• Expansion Slots

• AMD Ryzen 5000 and 3000 Series/ 5000 and 4000 G-Series Desktop Processors
• 1 x PCIe 4.0 x16 SafeSlot (supports x16 mode)
• AMD B550 chipset
• 1 x PCIe 3.0 x16 slot (supports x4 mode)*
• 3 x PCIe 3.0 x1
• *Share bandwidth with PCIe3.0 x1_1, PCIe3.0 x1_2, PCIe3.0 x1_3

• Multi-GPU Support

• 3rd and 2nd Gen AMD Ryzen™ Processors
• Supports NVIDIA© 2-Way SLI© Technology
• Supports AMD 3-Way CrossFireX™ Technology
• 2nd and 1st Gen AMD Ryzen with Radeon™ Vega Graphics Processors
• Supports AMD 2-Way CrossFireX™ Technology

• Storage

• AMD Ryzen 5000 and 3000 Series/ 5000 and 4000 G-Series Desktop Processors
• M.2_1 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 & SATA modes)
• AMD B550 Chipset:
• M.2_2 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 3.0 x4 & SATA modes)*
• 6 x SATA 6Gb/s ports
• Support RAID 0, 1, 10
• * When the M.2_2 Socket 3 is populated , SATA6G_5/6 ports will be disabled.

• Ethernet

• 1 x Intel© 2.5Gb Ethernet
• ASUS LANGuard

• USB

• Rear USB:
• Total 8 ports
• 2 x USB 3.2 Gen 2 port(s) (1 x Type-A + 1 x Type-C©)
• 4 x USB 3.2 Gen 1 port(s) (4 x Type-A)
• 2 x USB 2.0 port(s)
• Front USB:
• Total 6 ports
• 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports
• 2 x USB 2.0 header(s) support(s) additional 4 USB 2.0 ports

• Audio

• ROG SupremeFX 7.1-Channel High Definition Audio CODEC S1220A
• Impedance sense for front and rear headphone outputs
• Jack-detection, Multi-streaming, Front Panel Jack-retasking
• High quality 120 dB SNR stereo playback output and 113 dB SNR recording input
• Supports up to 32-Bit/192kHz playback*
• Audio Features
• SupremeFX Shielding Technology
• Dual OP Amplifiers
• Premium audio capacitors
• Audio cover
• * Due to limitations in HDA bandwidth, 32-Bit/192 kHz is not supported for 8-Channel audio.

• Back Panel I/O Ports

• 5 x Audio jacks
• 1 x Optical S/PDIF out
• 1 x BIOS FlashBackTM button
• 1 x DisplayPort
• 1 x HDMITM port
• 1 x Intel© I225-V 2.5G Ethernet
• 2 x USB 3.2 Gen 2 ports (1 x Type-A + 1 x USB Type-C©)
• 4 x USB 3.2 Gen 1 port(s)
• 2 x USB 2.0 port(s)

• Internal I/O Connectors

• Fan and cooling related
• 1 x 4-Pin AIO_Pump header
• 1 x 4-Pin CPU fan header
• 1 x 4-Pin CPU_OPT fan header
• 3 x 4-Pin Chassis fan headers
• Power related
• 1 x 24-pin main power connector
• 1 x 8-pin +12V power connector
• 1 x 4-pin +12V power connector
• Storage related
• 2 x M.2 slots (Key M)
• 6 x SATA 6Gb/s ports
• USB ports
• 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports
• 2 x USB 2.0 headers support additional 4 USB 2.0 ports
• Miscellaneous
• 1 x AURA addressable Gen 2 header
• 2 x AURA RGB headers
• 1 x Clear CMOS header
• 1 x Front panel audio header (AAFP)
• 1 x 20-3 pin System Panel header
• 1 x Thermal sensor header
• 1 x Thunderbolt header

• Special Features

• Aura Sync
• Standard RGB header(s)
• Addressable Gen 2 RGB header(s)
• ASUS Q-Design
• ASUS Q-DIMM
• ASUS Q-LED (DRAM [yellow],CPU [red], VGA [white], Boot Device [yellow green)
• ASUS Q-Slot
• ASUS Thermal Solution
• Aluminum M.2 heatsink
• ASUS EZ DIY
• BIOS Flashback button
• BIOS FlashBack LED
• Clear CMOS header
• Procool
• Pre-mounted I/O shield
• SafeSlot

• Software Features

• ROG Exclusive Software
• RAMCache III
• ROG CPU-Z
• GameFirst VI
• Sonic Studio III + Sonic Studio Virtual Mixer
• Sonic Radar III
• DTS© Sound Unbound
• Overwolf
• Anti-virus software
• ASUS Exclusive Software Features
• Armoury Crate
• Aura Creator
• Aura Sync
• AI Noise Cancelling Microphone
• AI Suite 3:
• PPSU
• EPU
• DIGI+ VRM
• Fan Xpert 4
• TurboV EVO
• EZ update
• WinRAR
• UEFI BIOS
• ASUS EZ DIY
• ASUS CrashFree BIOS 3
• ASUS EZ Flash 3
• ASUS UEFI BIOS EZ Mode

• BIOS

• 256 Mb Flash ROM, UEFI AMI BIOS

• Manageability

• WOL by PME, PXE

• Accessories

• Cables
• 1 x Addressable RGB extension cable
• 4 x SATA 6Gb/s cables
• Miscellaneous
• 1 x Cable ties pack
• 1 x M.2 Rubber Package
• 1 x M.2 SSD screw package
• 1 x ROG STRIX sticker
• 1 x ROG STRIX thank you card
• Installation Media
• 1 x Supporting DVD
• Documentation
• 1 x User manual

• Operating System

• Windows 10 64bit
• Windows© 10 64-bit, Windows© 11 64-bit

• Form Factor

• ATX
• 30.5cm x 24.4cm
