TP-LINK INSIGHT S385PI IP CSŐKAMERA (8MP, 1,65MM, IP67, H265+, IR20M, 12VDC/POE, SD; MIKR., HANGSZ.; FÉM)

• Kamera

• Képérzékelő
• 1/2.7" Progressive Scan CMOS
• Shutter Speed
• 1/3 to 1/10000 s
• Slow Shutter
• Yes
• Min. szükséges megvilágítás
• 0.005 Lux; 0 Lux with IR Light
• Day/Night Mechanism
• IR Cut Filter
• Day/Night Switch
• Unified/ Scheduled/ Auto

• LENS

• Type
• Fixed Focal Lens
• Focal Length
• 1.65 mm
• Aperture
• F2.0
• FOV
• Horizontal FOV: 180°
• Vertical FOV: 86°
• Diagonal FOV: 180°
• Lens Mount
• M12
• DORI Distance
• 1.65mm:
• D: 144.36 ft (44 m)
• O: 60.15 ft (18.33 m)
• R: 28.87 ft (8.8 m)
• I: 14.44 ft (4.4 m)

• Angle Adjustment (Manual)

• Range
• Pan: 0° to 360°, Tilt: 0° to 90°, Rotation: 0° to 360°

• ILLUMINATOR

• IR LED
• Quantity: 4
• Range: 65.62 ft (20 m)*1
• Wavelength: 850nm
• Illuminator On/Off Control
• Auto/Scheduled/Always on/Always off

• VIDEO

• Max. Resolution
• 3840 x 2160
• Main Stream
• Frame Rate:
• 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
• 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
• Resolution:
• 3840x2160,2560x1440,2304x1296,2048x1280,1920x1080,1280x720
• Note:
• If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps.
• Sub-Stream
• Frame Rate:
• 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
• 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
• Resolution:
• 848x480,704x576, 640x480, 640x360,352x288, 320x240
• Note:
• If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps.
• Bit Rate Control
• CBR, VBR
• Video Compression
• Main Stream: H.265+/H.265/H.264+/H.264
• Sub-Stream: H.265/H.264
• H.264 Type
• High Profile
• H.264+
• Main Stream Supported
• H.265 Type
• Main Profile
• H.265+
• Main Stream Supported
• Video Bit Rate
• Main Stream: 256 Kbps to 8 Mbps
• Sub-Stream: 64 Kbps to 1024 Kbps

• Image

• Image Settings
• Mirror
• Brightness
• Contrast
• Saturation
• Sharpness
• Exposure
• WDR
• White Balance
• Prevent Overexposure to Infrared Light
• HLC Adjustable by Client Software
• Image Enhancement
• BLC/3D DNR/HLC/SmartIR
• Wide Dynamic Range
• 120 dB
• SNR
• > 52 dB
• Image Parameters Switch
• Yes
• Privacy Mask
• Up to 4 Masks
• ROI
• 4 Regions
• OSD Setting
• Yes

• Hang

• Hangkommunikáció
• Two-Way Audio
• Hangbemenet
• Built-in Microphone
• Audio In Interface
• Hangkimenet
• Built-in Speaker
• Audio Out
• Interface
• Hangtömörítés
• Yes
• Audio Sampling Rate
• 8KHz
• Environment Noise Filtering
• Yes
• Audio Bit Rate
• 64 Kbps(G.711 alaw)

• Hálózat

• Szabvány
• TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP
• ONVIF
• Yes
• API
• Open Network Video Interface (Profile S/T/G)
• Simultaneous Live View
• 3 Main Streams & 3 Sub-Streams
• Client
• VIGI App, VIGI Security Manager, Web UI, VIGI VMS, VIGI Cloud VMS
• Web Browser
• Google Chrome© 57 and above
• Firefox© 52 and above
• Safari© 11 and above
• Microsoft© Edge 91 and above
• Cloud
• Yes
• Biztonság
• Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication

• Figyelmeztetési és eseménykezelési vezérlés

• Smart Event
• Intrusion Detection
• Line-Crossing Detection
• Region Entering Detection
• Region Exiting Detection
• Object Abandoned Detection
• Object Removal Detection
• Loitering Detection
• People Detection
• Vehicle Detection
• Abnormal Sound Detection
• Scene Change Detection
• Basic Event
• Motion Detection (Enhanced with Human & Vehicle Classification for more accurate alerts)
• Video Tampering Detection
• Exception ( Illegal Login)
• Alarm Input Device
• Alarm Linkage
• Memory Card Video Recording
• Upload to FTP Server
• Alarm Output Device
• Push Notifications
• Send to Alarm Server
• Active Defence-Sound Alarm
• Active Defence-Light Alarm
• Email Alarm

• Deep Learning Function

• People & Vehicle Analytics
• Search and filter to people or vehicle of interest based on many different attributes, making post-event search faster and easier. *2

• Fizikai kezelőfelület

• Hálózati csatlakozás
• 1 RJ45 10/100M Self-Adaptive Ethernet Port, PoE
• Alarm
• 1 Alarm In, 1 Alarm Out
• Red-Blue Warning Lights
• Reset Button
• Yes
• Power
• DC Power Port
• On-board Storage
• Built-In Memory Card Slot, Support MicroSD Card, up to 512 GB*5
• Built-in Microphone
• Yes; Records Anything Going on within a 15-ft Radius of the Camera
• Built-in Speaker
• Yes
• Audio
• 1 Audio In, 1 Audio Out

• Általános

• Operating Temperature
• -30? to 60 °C
• Storage Temperature
• -40 to 60 °C
• Operating Humidity
• 95% or Less (Non-Condensing)
• Storage Humidity
• 95% or Less (Non-Condensing)
• Csomagolás tartalma
• VIGI Network Camera
• Quick Start Guide
• Waterproof Cable Attachments
• Mounting Accessories
• Material
• Metal
• Net Weight
• 1.01Kg
• Power Supply
• 12V DC +/- 5%, Max. 18W, 5.5 mm Coaxial Power Plug
• PoE: 802.3at, Class 4, Max. 21W
• Protection
• IP67 Weatherproof, IK10 Vandal Proof
• Product Dimensions (L x W x H)
• 10.5 × 3.9 × 4 in (266 × 100 × 101 mm)
• Certifications
• CE, NTRA, VCCI, KC, BSMI, FCC, IP67, IK10, ONVIF
