ZEBRA VONALKÓD OLVASÓ, VEZETÉKES, DS2208, 1D, 2D, MULTI-IF, KIT(USB), FEKETE

• Physical Characteristics

• Dimensions
• Corded DS2208:
• 6.5 in. H x 2.6 in. W x 3.9 in. D
• 16.5 cm H x 6.6 cm W x 9.9 cm D
• Weight
• Corded DS2208: 5.7 oz. / 161.6 g
• Input Voltage Range
• DS2208: 4.5 to 5.5 VDC Host Powered; 4.5 to 5.5 VDC External Power Supply
• Current
• Corded DS2208 Operating Current at
• Nominal Voltage (5.0V): 250 mA (typical).
• (Note: Auto-Aim and Illumination on Acquiring Image)
• Corded DS2208 Standby Current (idle) at
• Nominal Voltage (5.0V): 150 mA (typical).
• (Note: Auto-Aim On)
• Micro USB Cable:
• 500 mA (typical) Standard USB; 1100 mA
• (typical) BC 1.2 USB
• Supported Host Interfaces
• USB, RS232, Keyboard Wedge, TGCS (IBM)
• 46XX over RS485
• Keyboard Support
• Supports more than 90 international keyboards
• User Indicators
• Direct Decode Indicator; good decode LEDs;
• Rear view LEDs; beeper (adjustable tone and
• volume)

• Performance Characteristics

• Motion Tolerance (Handheld)
• Up to 5 in./13 cm. per second for 13 mil UPC
• Swipe Speed (Hands-Free)
• Up to 30.0 in./76.2 cm. per second for 13 mil UPC
• Light Source
• Aiming Pattern: Linear 624nm Amber LED
• Illumination
• (2) 645nm Super-Red LEDs
• Imager Field of View
• 32.8° H x 24.8° V Nominal
• Image Sensor
• 640 x 480 pixels
• Minimum Print Contrast
• 25% minimum reflective difference
• Skew/Pitch/Roll Tolerance
• +/- 65°; +/- 65°; 0-360°
• Minimum Element Resolution
• Code 39 - 4.0 mil; Code 128 - 4.0 mil;
• Data Matrix - 6.0 mil; QR Code - 6.7 mil

• User Environment

• Operating Temperature
• DS2208Imager:
• 32.0° to 122.0° F/0.0° to 50.0° C
• Storage Temperature
• -40.0° to 158.0° F/-40.0° to 70.0° C
• Humidity
• 5% to 95% RH, non-condensing
• Drop Specification
• Designed to withstand multiple drops at 5.0 ft./1.5 m to concrete
• Tumble Specification
• Designed to withstand 250 tumbles in 1.5 ft./.5 m tumbler1
• Environmental Sealing
• IP52
• Electrostatic Discharge (ESD)
• DS2208: ESD per EN61000-4-2, +/-15 KV Air, +/-8 KV Direct, +/-8 KV Indirect
• Ambient Light Immunity
• 0 to 10,000 Foot Candles/0 to 107,600 Lux

• Battery

• Battery Capacity/Battery Type 2
• ,400 mAh Li-Ion Battery
• Scans Per Battery Charge2
• 110,000 scans at 60 Scans per Minute or 50,000 scans at 10 Scans per Minute
• Operating Time Per Full Charge2
• 84.0 Hours
• Charge Time (from Empty)
• 14 Hour Shift Hours / Full Charge Hours
• Standard USB
• 14 Hour Shift Hours: 4
• Full Charge Hours: 17
• BC1.2 USB
• 14 Hour Shift Hours: 1
• Full Charge Hours: 5
• External 5V Source
• 14 Hour Shift Hours: 1
• Full Charge Hours: 5
• Micro USB
• 14 Hour Shift Hours: 1
• Full Charge Hours: 7
• BC1.2 Micro USB
• 14 Hour Shift Hours: 1
• Full Charge Hours: 4

• Decode Capabilities

• Input Voltage Range
• DS2208: 4.5 to 5.5 VDC
• Host Powered; 4.5 to 5.5 VDC External Power Supply
• 1D
• Code 39, Code 128, Code 93, Codabar/NW7,
• Code 11, MSI Plessey, UPC/EAN, I 2 of 5, Korean 3 of 5, GS1 DataBar, Base 32 (Italian Pharma)
• 2D
• PDF417, Composite Codes, TLC-39, Aztec, DataMatrix, MaxiCode, QR Code, Micro QR, Han Xin, Postal Codes

• Recommended Services

• Zebra OneCare Select; Zebra OneCare Essential

• Utilities and Management

• 123Scan
• Programs scanner parameters, upgrades
• firmware, provides scanned barcode data and
• prints reports. www.zebra.com/123Scan
• Symbol Scanner SDK
• Generates a fully-featured scanner application, including documentation, drivers, test utilities and sample source code.
• www.zebra.com/scannersdkforwindows
• Scanner Management Service (SMS)
• Remotely manages your Zebra scanner and queries its asset information.
• www.zebra.com/sms

• Decode Ranges (Typical)

• Code 39
• Resolution: 5 mil
• Near: .2in./.5cm
• Far: 6.0 in/15.2 cm.
• Code 128
• Resolution: 5 mil
• Near: .6in./1.5 cm.
• Far: 4.0 in./10.1 cm.
• PDF417
• Resolution: 6.7 mil
• Near: .8 in./2.0 cm
• Far: 5.7 in/14.5 cm.
• UPC
• Resolution: 13 mil (100%)
• Near: .5 in./.1.3 cm
• Far: 14.5 in./36.8 cm.
• Data Matrix
• Resolution: 10 mil
• Near: .3in./.8 cm.
• Far: 6.2 in./15.7 cm.
• QR
• Resolution: 20 mil
• Near: .0 in./.0cm
• Far: 11 in./27.9 cm.

Garancia fogyasztók részére

• 2 év kötelező jótállás + 3 év gyártó által biztosított szervizgarancia

Garancia nem fogyasztók részére

• 5 év gyártó által biztosított szervizgarancia
